DIN1870 HSS Jobber Drills HSS Drill Extra Long Taper Shank Milled Black Twist Drill Bit for Metal Drilling (SED-HTSML)

SHANGHAI EASYDRILL INDUSTRIAL CO., LTD.
  • Customized：Customized
  • Standard：DIN
  • Length：Taper-length
  • Type：Twist Drill Bit
  • Material：High Speed Steel
  • Usage：Metal Drilling

Base Info

  • Model NO.：SED-HTSML
  • Shank：Taper Shank
  • Manufacturing Art：Forged
  • Surface Finish：Black
  • Angle：135 or 118
  • Min Qty：100PCS
  • Transport Package：Oil Paper, Paper Box, Plastic Tube, Set Cases
  • Specification：SGS
  • Trademark：EASYDRILL
  • Origin：China
  • HS Code：820750900
  • Production Capacity：20, 000PCS,Month

Description

Procuct NameDIN1870 Extra Long Taper Shank Milled Black Drill Bit for Metal DrillingMaterialHSS 4241 4341 6542-M2 (Cobalt 5% M35 is Available)ProcessMilled (Roll Forged is Available)StandardDIN1870 (ANSI, DIN345, DIN341 are Also Available)MT No.No.1 to No.4Size10mm-50mmFlute TypeType N, Right Hand CuttingPoint Angle118 Degree (135 Degree Split Point, Thinning Point are Also Available)Surface FinishBlack Oxide (Black &White, Gray & Bright, Bright, Amber Color, Titanium Coating are Also Available)PackageOne Piece in Paper Box,Plastic Box,Wood Box.Features1. Extra-long flute is ideal for deep hole drilling of difficult-to-cut materials and efficient machining of deep holes
2. High-speed steel tools are good for most general purpose applications, offering a combination of hardness and toughness for wear resistance.
3. Taper shank drills are designed to give maximum performance in drilling many different materials, under a wide range of applications.
4. High performance hss special drill bit with morse taper shank for high precision drilling of larger bore diameter
5. Black oxide treatment adds lubricity and creates small pockets on the surface of the tool that act to hold coolant near the cutting edge.
6. Usage for Metal Drilling, cast steel, grey cast iron, malleable iron, sintered metal and low hardness alloyed materials

Details:
1. Process: 6.0-33.0mm Roll Forged, 31.0-100.0mm Milled
2. Standard: Strictly as per DIN345 specification requested.
Point Angle:118 angle and 135angle
3. Application: Drilling deep hole on Non-Alloy Steel, Alloy Steel, Grey Cast Iron, Malleable Cast Iron, special aluminum or magnesium alloy.
4.118degree or 135 degree
5. Package: One PC into a Paper Tube or Plastic Tube, also Set Cases are available.
