Concrete Dry Drill Bit Diamond Tool Diamond Core Drill Bit Green Concrete Core Drill Bit

QUANZHOU ZHUOSHI SUPERHARD TOOL CO., LTD.
  • Type：Core Drill Bit
  • Material：Diamond
  • Application：for Drilling Reinforced Concrete, Green Concrete
  • Welding Method：Laser, Silvered Brazed
  • Sizes：68mm, 82mm
  • Segment Height：8mm, 10mm

Base Info

  • Model NO.：WSCDB-3
  • Segment Shape：Turbo Segmented
  • Overall Length：70-90
  • Connection：M16
  • Working Condition：Dry and Wet
  • Delivery Time：7-10 Days
  • MOQ：2PCS
  • Transport Package：Paper Cartons and Plywood Cartons
  • Specification：13-600mm
  • Trademark：WANSHIN
  • Origin：Quanzhou
  • HS Code：82075010
  • Production Capacity：1000PCS,Month

Description

No.DiamterSegment No.Segment Size1¢13.3(1/2")

Continue Rim¢13.3x3.2x102¢16.5 (5/8")¢16.5x3.2x103¢19.7(3/4")¢19.7x3.2x104¢22.9(7/8")¢22.9x3.2x105¢26(1")¢26x3.2x106¢29.2(1-1/8")¢29.2x3.2x107¢32.4(1-1/4")¢32.4x3.2x108¢35.6(1-3/8")¢35.6x3.2x109¢38.7(1-1/2")¢38.7x3.2x1010¢41.9(1-5/8")¢41.9x3.2x1011¢45(1-3/4")¢45x3.2x1012¢48.3(1-7/8")¢48.3x3.2x1013¢51(2")425.4x3.6x12-V15¢64(2.5")625.4x3.6x12-V16¢76(3")725.4x3.6x12-V17¢89(3.5")825.4x3.8x12-V18¢102(4")1025.4x4.0x12-V19¢115(4.5")1125.4x4.0x12-V20¢127(5")1225.4x4.0x12-V21¢152(6")1425.4x4.2x12-V22Ø178(7")1525.4x4.4x12-V23Ø204(8")1625.4x4.4x12-V28Ø225(9")1725.4x5.1x12-V29Ø254(10")1825.4x5.1x12-V30Ø305(12")2025.4x5.1x12-V31Ø 356(14")2225.4x5.1x12-V
