8PCS Cylindrical Shank 90 Degree 3 Flute HSS Countersink Drill Bit Set for Metal (SED-CS3F-8)

SHANGHAI EASYDRILL INDUSTRIAL CO., LTD.
  • Customized：Customized
  • Standard：DIN
  • Length：Jobber-length
  • Type：Countersink Drill Bit
  • Material：High Speed Steel
  • Usage：Metal Drilling

Base Info

  • Model NO.：SED-CS3F-8
  • Dia Size：5mm,6mm,8mm,10mm
  • Production Art：Fully Ground or Forged
  • Min Quantity：100PCS,Size
  • Packaging：PVC Bag,Setcase,Plastic Box,Metal Box
  • Surface Finish：Tin Coated
  • Transport Package：PVC Bag, Blister Card, Plastic Box, Metal Box etc
  • Specification：ISO9001, SGS, CE
  • Trademark：EASYDRILL
  • Origin：China
  • HS Code：820750900
  • Production Capacity：200, 000PCS,Month

Description

Product Name8Pcs Cylindrical Shank 90 Degree  3 Flute HSS Countersink Drill Bit Set for Metal DeburringSize

6.3mm, 8.3mm, 10.4mm, 12.4mm, 16.5mm, 20.5mm

MaterialHigh Speed Steel      (Cobalt5%-M35, Carbide Steel , Carbon Steel are Available)Flute Type

3 Flute    (5 Flute, Single Flute, 0 Flute,  6 Flute, 7 Flute, Multi Flute  are Available)

Cutting Angle90°        (120°, 60 °, 82°  are Available)Shank TypeRound Shank      (Hex Shank, Taper Shank, Tri-Flat Shank, Weldon Shank, Long Shank are Available)Surface FinishTin-Coated      (White, Black and White, Black, Black and Yellow  are Available)Package8Pcs in Wood Case        (Plastic Case, Tin Box, Double Blister Card are Available)Features

1. This set of 8 90-degree 3-edge drilling cutters is suitable for working on metal and certain non-metallic materials, such as coal steel, light iron, insulation boards, PVC panels, aluminum, wood hard and soft, etc.

2.High-speed steel tools are good for most general purpose applications, offering a combination of hardness and toughness for wear resistance.

3.The surface is titanium coated, sturdy and durable, not easy to rust, long service life.

4.Round shanks allow use with a wide variety of toolholding systems.

5.Ideal for making countersunk countersunk holes and countersunk holes for plugs.
