DIN335D 90 Degree 3 Flute HSS Countersink Drill Bit with Morse Taper Shank for Metal Deburring (SED-CS3F-TS)

SHANGHAI EASYDRILL INDUSTRIAL CO., LTD.
  • Customized：Customized
  • Standard：DIN
  • Length：Jobber-length
  • Type：Countersink Drill Bit
  • Material：High Speed Steel
  • Usage：Metal Drilling

Base Info

  • Model NO.：SED-CS3F-TS
  • Dia Size：1,2 Inch, 5,8 Inch, 3,4 Inch
  • Production Art：Fully Ground or Forged
  • Min Quantity：100PCS,Size
  • Package：PVC Bag,Setcase,Plastic Box,Metal Box
  • Surface Finish：Original
  • Transport Package：PVC Bag, Blister Card, Plastic Box, Metal Box etc
  • Specification：ISO9001, SGS, CE
  • Trademark：EASYDRILL
  • Origin：China
  • HS Code：820750900
  • Production Capacity：200, 000PCS,Month

Description

Product NameDIN335D 90 Degree 3 Flute HSS  Countersink Drill Bit with Morse Taper Shank  for Metal DeburringSize

15.0MM - 80.0MM

MaterialHigh Speed Steel       (Cobalt5%-M35, Carbide Steel, Carbon Steel are Available)Flute Type

3 Flute    (5 Flute, Single Flute, 0 Flute,  6 Flute, 7 Flute,  Multi Flute  are Available)

Cutting Angle90°        (120°, 60 °, 82°  are Available)Shank TypeTaper Shank       (Round Shank, Hex Shank,  Tri-Flat Shank, Weldon Shank, Long Shank are Available)Surface FinishBlack and White       (White, Tin-Coated, Black, Black and Yellow are Available)Package1 Piece in One Plastic Box       (Double Blister Card is Available)Features

1. Three-flute designed to reduce clogging, improve clearance and be chatter free

2.High-speed steel tools are good for most general purpose applications, offering a combination of hardness and toughness for wear resistance.

3.Black oxide finish for increased wear resistance and added lubricity standard from stock

4.MT shank allows drills installed directly into the machine's spindle for high-torque applications

5.Made from industrial grade High-Speed Steel for increased durability.

6.Ideal for wooden planks,fiberboard,particle board,plywood,plastic,alumiumn board ,pcb board and more
