• Model NO.：962
• Steel Type：HSS M35
• Flute Type：N
• Rotation Direction：Right Hand
• Surface Treatment：Amber Finished
• Tip Point：Multi-Angle Ground
• Marking：Stamped Marking
• Standard Type：DIN338rn
• Shank Type：Tri-Flat Shank
• Transport Package：Blister, Skin, PVC Bag, Color Paper Hanger, Paper
• Specification：3mm to 16mm diameter
• Trademark：OEM, HTT
• Origin：China
• HS Code：8207509000
• Production Capacity：4800000PCS,Year

Basic Info.

Model NO. 962 Steel Type HSS M35 Flute Type N Rotation Direction Right Hand Surface Treatment Amber Finished Tip Point Multi-Angle Ground Marking Stamped Marking Standard Type DIN338rn Shank Type Tri-Flat Shank Transport Package Blister, Skin, PVC Bag, Color Paper Hanger, Paper Specification 3mm to 16mm diameter Trademark OEM, HTT Origin China HS Code 8207509000 Production Capacity 4800000PCS/Year

Product Description

*HSS M35 Cobalt 5% Multi-angle Speedy Twist Drill Bit, Fully Ground, Amber finish, DIN338RN , Tri-flat Shank for drilling holes in various metal sheets, stainless steel, inox sheet, alloyed steel, unalloyed steel, non-ferrous metal, stainless steel sheet, fiberboard, wood board, etc.

* Strict and special hardening craftsmanship to realize the M35 HSS higher durability and sharpness maintaining for longer time.

* Fully ground does the precise size controlling under DIN338 standard and run-out concentricity under DIN1414 for H8 correctness touching.



*Other special sizes are also available on the customers' special request.
*Diameter 13.5mm to 16mm with the reduced Tri-flat shank 12.7mm diameter.

Item Number	Diameter(mm)	Flute Length(mm)	Overall Length(mm)
962.3380301	3.0	33	61
962.3380311	3.1	36	65
962.3380321	3.2	36	65
962.3380331	3.3	36	65
962.3380341	3.4	39	70
962.3380351	3.5	39	70
962.3380361	3.6	39	70
962.3380371	3.7	39	70
962.3380381	3.8	43	75
962.3380391	3.9	43	75
962.3380401	4.0	43	75
962.3380411	4.1	43	75
962.3380421	4.2	43	75
962.3380431	4.3	47	80
962.3380441	4.4	47	80
962.3380451	4.5	47	80
962.3380461	4.6	47	80
962.3380471	4.7	47	80
962.3380481	4.8	52	86
962.3380491	4.9	52	86
962.3380501	5.0	52	86
962.3380511	5.1	52	86
962.3380521	5.2	52	86
962.3380531	5.3	52	86
962.3380541	5.4	57	93
962.3380551	5.5	57	93
962.3380561	5.6	57	93
962.3380571	5.7	57	93
962.3380581	5.8	57	93
962.3380591	5.9	57	93
962.3380601	6.0	57	93
962.3380611	6.1	63	101
962.3380621	6.2	63	101
962.3380631	6.3	63	101
962.3380641	6.4	63	101
962.3380651	6.5	63	101
962.3380661	6.6	63	101
962.3380671	6.7	63	101
962.3380681	6.8	69	109
962.3380691	6.9	69	109
962.3380701	7.0	69	109
962.3380711	7.1	69	109
962.3380721	7.2	69	109
962.3380731	7.3	69	109
962.3380741	7.4	69	109
962.3380751	7.5	69	109
962.3380761	7.6	75	117
962.3380771	7.7	75	117
962.3380781	7.8	75	117
962.3380791	7.9	75	117
962.3380801	8.0	75	117
962.3380811	8.1	75	117
962.3380821	8.2	75	117
962.3380831	8.3	75	117
962.3380841	8.4	75	117
962.3380851	8.5	75	117
962.3380861	8.6	81	125
962.3380871	8.7	81	125
962.3380881	8.8	81	125
962.3380891	8.9	81	125
962.3380901	9.0	81	125
962.3380911	9.1	81	125
962.3380921	9.2	81	125
962.3380931	9.3	81	125
962.3380941	9.4	81	125
962.3380951	9.5	81	125
962.3380961	9.6	87	133
962.3380971	9.7	87	133
962.3380981	9.8	87	133
962.3380991	9.9	87	133
962.3381001	10.0	87	133
962.3381021	10.2	87	133
962.3381051	10.5	87	133
962.3381101	11.0	94	142
962.3381151	11.5	94	142
962.3381201	12.0	101	151
962.3381251	12.5	101	151
962.3381301	13.0	101	151
962.3381351	13.5	108	160
962.3381401	14.0	108	160
962.3381451	14.5	108	160
962.3381501	15.0	108	160
962.3381551	15.5	114	178
962.3381601	16.0	114	178
