• Model NO.：2321
• Carbide Type：Virgin Yg9
• Steel Type：40cr
• Surface Treatment：Shot-Peened
• Cutter Type：SSD Cross Cutter Tip
• Flute Type：F
• Marking：Stamped
• Welding Type：AVS. (Automatic Vacuum Soldering)
• Certificated：Bosch Audited SDS-Plus Logo
• Transport Package：Clip Hanger, Color Paper Hanger, Paper Box, Tubes
• Specification：Diameter 5mm to 32mm
• Trademark：OEM, HTT
• Origin：China
• HS Code：8207509000
• Production Capacity：3600000,Year

Basic Info.

Model NO. 2321 Carbide Type Virgin Yg9 Steel Type 40cr Surface Treatment Shot-Peened Cutter Type SSD Cross Cutter Tip Flute Type F Marking Stamped Welding Type AVS. (Automatic Vacuum Soldering) Certificated Bosch Audited SDS-Plus Logo Transport Package Clip Hanger, Color Paper Hanger, Paper Box, Tubes Specification Diameter 5mm to 32mm Trademark OEM, HTT Origin China HS Code 8207509000 Production Capacity 3600000/Year

Product Description

*Hammer Drill SDS plus for Concrete Stone Drilling, Manufactured by HTT, Patented SSD cross cutter carbide tip made of virgin YG9 formulation.

*Special design of the SSD cross carbide tip fasts the drilling speed with multi angle Turbo wave cutting edges.

*F type of flute 3DMAX design maximizes the drilling dust rejection rate to fast the drilling speed with more comfortable operation feelings.

* Lower vibration for easy longer time drilling job.

* SDS-plus shank all 100% pass Bosch audited SDS-plus gouge inspection with the stamped logo of SDS-plus audited by Bosch.

* SGS approved anti-rust oil treatment to protect the final users under Reach standard.




*Other special sizes are available on the customers' special requests.

Item Number	Diameter(mm)	Working Length(mm)	Overall Length(mm)
2321.050110	5	60	110
2321.055110	5.5	60	110
2321.060110	6	60	110
2321.065110	6.5	60	110
2321.070110	7	60	110
2321.080110	8	60	110
2321.090110	9	60	110
2321.100110	10	60	110
2321.110110	11	60	110
2321.050160	5	110	160
2321.055160	5.5	110	160
2321.060160	6	110	160
2321.065160	6.5	110	160
2321.070160	7	110	160
2321.080160	8	110	160
2321.090160	9	110	160
2321.100160	10	110	160
2321.110160	11	110	160
2321.120160	12	110	160
2321.130160	13	110	160
2321.140160	14	110	160
2321.150160	15	110	160
2321.160160	16	110	160
2321.180160	18	110	160
2321.190160	19	110	160
2321.200160	20	110	160
2321.220160	22	110	160
2321.240160	24	110	160
2321.250160	25	110	160
2321.260160	26	110	160
2321.280160	28	110	160
2321.300160	30	110	160
2321.320160	32	110	160
2321.050180	5	130	180
2321.055180	5.5	130	180
2321.060180	6	130	180
2321.065180	6.5	130	180
2321.080180	8	130	180
2321.100180	10	130	180
2321.050210	5	160	210
2321.055210	5.5	160	210
2321.060210	6	160	210
2321.065210	6.5	160	210
2321.070210	7	160	210
2321.080210	8	160	210
2321.090210	9	160	210
2321.100210	10	160	210
2321.110210	11	160	210
2321.120210	12	160	210
2321.130210	13	160	210
2321.140210	14	160	210
2321.150210	15	160	210
2321.160210	16	160	210
2321.180210	18	160	210
2321.190210	19	160	210
2321.200210	20	160	210
2321.220210	22	160	210
2321.240210	24	160	210
2321.250210	25	160	210
2321.260210	26	160	210
2321.280210	28	160	210
2321.300210	30	160	210
2321.320210	32	160	210
2321.050260	5	210	260
2321.055260	5.5	210	260
2321.060260	6	210	260
2321.065260	6.5	210	260
2321.070260	7	210	260
2321.080260	8	210	260
2321.090260	9	210	260
2321.100260	10	210	260
2321.110260	11	210	260
2321.120260	12	210	260
2321.130260	13	210	260
2321.140260	14	210	260
2321.150260	15	210	260
2321.160260	16	210	260
2321.180260	18	210	260
2321.190260	19	210	260
2321.200260	20	210	260
2321.220260	22	210	260
2321.240260	24	210	260
2321.250260	25	210	260
2321.260260	26	210	260
2321.280260	28	210	260
2321.300260	30	210	260
2321.320260	32	210	260
2321.050310	5	260	310
2321.055310	5.5	260	310
2321.060310	6	260	310
2321.065310	6.5	260	310
2321.070310	7	260	310
2321.080310	8	260	310
2321.090310	9	260	310
2321.100310	10	260	310
2321.110310	11	260	310
2321.120310	12	260	310
2321.130310	13	260	310
2321.140310	14	260	310
2321.150310	15	260	310
2321.160310	16	260	310
2321.180310	18	260	310
2321.190310	19	260	310
2321.200310	20	260	310
2321.220310	22	260	310
2321.240310	24	260	310
2321.250310	25	260	310
2321.260310	26	260	310
2321.280310	28	260	310
2321.300310	30	260	310
2321.320310	32	260	310
2321.050350	5	300	350
2321.055350	5.5	300	350
2321.060350	6	300	350
2321.065350	6.5	300	350
2321.070350	7	300	350
2321.080350	8	300	350
2321.090350	9	300	350
2321.100350	10	300	350
2321.110350	11	300	350
2321.120350	12	300	350
2321.130350	13	300	350
2321.140350	14	300	350
2321.150350	15	300	350
2321.160350	16	300	350
2321.180350	18	300	350
2321.190350	19	300	350
2321.200350	20	300	350
2321.220350	22	300	350
2321.240350	24	300	350
2321.250350	25	300	350
2321.260350	26	300	350
2321.280350	28	300	350
2321.300350	30	300	350
2321.320350	32	300	350
2321.050410	5	360	410
2321.055410	5.5	360	410
2321.060410	6	360	410
2321.065410	6.5	360	410
2321.070410	7	360	410
2321.080410	8	360	410
2321.090410	9	360	410
2321.100410	10	360	410
2321.110410	11	360	410
2321.120410	12	360	410
2321.130410	13	360	410
2321.140410	14	360	410
2321.150410	15	360	410
2321.160410	16	360	410
2321.180410	18	360	410
2321.190410	19	360	410
2321.200410	20	360	410
2321.220410	22	360	410
2321.240410	24	360	410
2321.250410	25	360	410
2321.260410	26	360	410
2321.280410	28	360	410
2321.300410	30	360	410
2321.320410	32	360	410
2321.050460	5	410	460
2321.055460	5.5	410	460
2321.060460	6	410	460
2321.065460	6.5	410	460
2321.070460	7	410	460
2321.080460	8	410	460
2321.090460	9	410	460
2321.100460	10	410	460
2321.110460	11	410	460
2321.120460	12	400	460
2321.130460	13	400	460
2321.140460	14	400	460
2321.150460	15	400	460
2321.160460	16	400	460
2321.180460	18	400	460
2321.190460	19	400	460
2321.200460	20	400	460
2321.220460	22	400	460
2321.240460	24	400	460
2321.250460	25	400	460
2321.260460	26	400	460
2321.280460	28	400	460
2321.300460	30	400	460
2321.320460	32	400	460
2321.060550	6	500	550
2321.065550	6.5	500	550
2321.070550	7	500	550
2321.080550	8	500	550
2321.090550	9	500	550
2321.100550	10	500	550
2321.110550	11	500	550
2321.120550	12	500	550
2321.130550	13	500	550
2321.140550	14	500	550
2321.150550	15	500	550
2321.160550	16	500	550
2321.180550	18	500	550
2321.190550	19	500	550
2321.200550	20	500	550
2321.220550	22	500	550
2321.240550	24	500	550
2321.250550	25	500	550
2321.260550	26	500	550
2321.280550	28	500	550
2321.300550	30	500	550
2321.320550	32	500	550
2321.060600	6	550	600
2321.065600	6.5	550	600
2321.070600	7	550	600
2321.080600	8	550	600
2321.090600	9	550	600
2321.100600	10	550	600
2321.110600	11	550	600
2321.120600	12	550	600
2321.130600	13	550	600
2321.140600	14	550	600
2321.150600	15	550	600
2321.160600	16	550	600
2321.180600	18	550	600
2321.190600	19	550	600
2321.200600	20	550	600
2321.220600	22	550	600
2321.240600	24	550	600
2321.250600	25	550	600
2321.260600	26	550	600
2321.280600	28	550	600
2321.300600	30	550	600
2321.320600	32	550	600
2321.080800	8	750	800
2321.090800	9	750	800
2321.100800	10	750	800
2321.110800	11	750	800
2321.120800	12	750	800
2321.130800	13	750	800
2321.140800	14	750	800
2321.150800	15	750	800
2321.160800	16	750	800
2321.180800	18	750	800
2321.190800	19	750	800
2321.200800	20	750	800
2321.220800	22	750	800
2321.240800	24	750	800
2321.250800	25	750	800
2321.260800	26	750	800
2321.280800	28	750	800
2321.300800	30	750	800
2321.320800	32	750	800
2321.101000	10	950	1000
2321.111000	11	950	1000
2321.121000	12	950	1000
2321.131000	13	950	1000
2321.141000	14	950	1000
2321.151000	15	950	1000
2321.161000	16	950	1000
2321.181000	18	950	1000
2321.191000	19	950	1000
2321.201000	20	950	1000
2321.221000	22	950	1000
2321.241000	24	950	1000
2321.251000	25	950	1000
2321.261000	26	950	1000
2321.281000	28	950	1000
2321.301000	30	950	1000
2321.321000	32	950	1000
