Drilling Tools

High Speed Steel Center Drill

Zhenjiang Scharp Machinery Tools Co., Ltd.
  • Customized:Customized
  • Standard:DIN, JIS, AISI
  • Length:Jobber-length
  • Type:Center Drill Bit
  • Material:High Speed Steel
  • Usage:Metal Drilling

Base Info

  • Model NO.:metric and inch
  • Size:0.5mm to 12mm
  • Transport Package:Plastic Box
  • Specification:0.5mm to 12.5mm
  • Trademark:stc
  • Origin:Jiangsu
  • HS Code:82077090
  • Production Capacity:100000PCS Per Month

Description

STC036-M, METRIC SIZE CENTER DRILLDIN333,  GOST14952FROM R, R TYPE, 60° Angle

 Pict











 Milled / Ground



 SizeBody DiameterOverall Length
 SizeBody DiameterOverall Length
 0.53.1525
 3.158500.83.1525
 4105613.1531.5
 512.5631.253.1531.5
 6.316711.6435.5
 820802540
 10251002.56.345
 12.531.5125






 FROM A, PLAIN TYPE, 60° Angle

 Pict











 Milled / Ground




 SizeBody DiameterOverall Length
 SizeBody DiameterOverall Length
 0.53.1525
 3.158500.83.1525
 4105613.1531.5
 512.5631.253.1531.5
 6.316711.6435.5
 820802540
 10251002.56.345
 12.531.5125






 FROM B, PLAIN TYPE, 60° & 120° Angle

 Pict




















 Milled / Ground




 SizeBody DiameterOverall Length
 SizeBody DiameterOverall Length
 1435.5
 414671.25540
 516751.66.345
 6.320802850
 8251002.51056
 1031.51253.1511.260










 STC037-M, METRIC SIZE CENTER DRILLS, Long Series, Form AFORM A, PLAIN TYPE, 60° Angle








 Pict






 Milled / Ground




 SizeBody DiameterOverall Length
 SizeBody DiameterOverall Length
 0.753.560
 38801460
 3101001.5560
 4101002680
 4121002.5880
