PDC Drag Bits with API Reg Pin for Quarrying

XIAMEN PRODRILL EQUIPMENT CO., LTD.
  • Material：PDC Cutter
  • Usage：Well Drilling
  • Diameter：75mm to 215.9 mm
  • Types：Ordinary Type; Reinforced Type; Super Strength Typ
  • Thread：Ny Female or Male Threads.
  • No. of Wing：3

Base Info

  • Model NO.：PDC Drag Bits
  • Cutter Materials：Polycrystalline Diamond Compacts
  • Transport Package：Wood Case
  • Specification：CE, SGS, ISO9001
  • Trademark：Prodrill
  • Origin：China
  • HS Code：82071990
  • Production Capacity：2000 PCS Per Month

Description

ModelDiameter(mm)PDC cutter typeBlade No.Suitable rock formationOperation mode75GD75Plane PDC, Cambered face PDC, GK PDC, ZX PDC3Soft, medium, medium-hardCutting80GD80Plane PDC, Cambered face PDC, GK PDC, ZX PDC3Soft, medium, medium-hardCutting90GD90Plane PDC, Cambered face PDC, GK PDC, ZX PDC3Soft, medium, medium-hardCutting94GD94Plane PDC, Cambered face PDC, GK PDC, ZX PDC3Soft, medium, medium-hard formationCutting98GD98Plane PDC, Cambered face PDC, GK PDC, ZX PDC3Soft, medium, medium-hardCutting113GD113Plane PDC, Cambered face PDC, GK PDC, ZX PDC3Soft, medium, medium-hardCutting120GD120Plane PDC, Cambered face PDC, GK PDC, ZX PDC3Soft, medium, medium-hardCutting133GD133Plane PDC, Cambered face PDC, GK PDC, ZX PDC3/4Soft, medium, medium-hardCutting140GD140Plane PDC, Cambered face PDC, GK PDC, ZX PDC3/4Soft, medium, medium-hardCutting153GD153Plane PDC, Cambered face PDC, GK PDC, ZX PDC3/4Soft, medium, medium-hardCutting171GD171Plane PDC, Cambered face PDC, GK PDC, ZX PDC4/5Soft, medium, medium-hardCutting191GD191Plane PDC, Cambered face PDC, GK PDC, ZX PDC4/5/6Soft, medium, medium-hardCutting215GD215.9Plane PDC, Cambered face PDC, GK PDC, ZX PDC6Soft, medium, medium-hardCutting
