7 1/2′′ IADC Code 127steel Tooth Three Cone Bits

Hejian Hengji Bit Manufacture Co., Ltd.
  • Material：Alloy Steel, Tungsten Carbide
  • Usage：Well Drilling
  • Certification：ISO
  • Model Number：Steel Tooth Bit, TCI Bit
  • Bearing Type：Sealed Bearing and Non-Sealed Bearing
  • Suitable Formation：Soft, Medium Soft, Hard, Medium Hard, Very Hard

Base Info

  • Model NO.：127 217
  • Color：Blue or Red
  • Transport Package：Wooden Case
  • Specification：according requirement
  • Trademark：HJ
  • Origin：China
  • HS Code：8207191
  • Production Capacity：500

Description

                                           HENGJI BIT SPECIFICATION Bit Size7 1/2'' IADC Code127SeriesHRTooth typeTCI/tungsten carbide insert Connection 4 1/2 API REG PINBearingrubber sealed bearing Nozzle three jet nozzles Rotary Speed(rpm) 150~70 Weight on Bit(KN/MM)0.35~0.9Applicationwater well,oil   well,HDD,exploration,etc
Formation Soft  formations with low compressive   strength and high drillability,such as mudstone,gypsum,salt,soft shale ,soft limestone,etc.Note: The upper limits of WOB and RPM in above table should not be used simultaneously.
  Note: The upper limits of WOB and RPM in above table should not be used simultaneously.7 1/2′′ IADC Code 127steel Tooth Three Cone Bits7 1/2′′ IADC Code 127steel Tooth Three Cone Bits7 1/2′′ IADC Code 127steel Tooth Three Cone Bits
Company Information
 Hejian Hengji Bit Manufacture Co.,LTD  is specialized in manufacturing high quality rock bit,especially for tricone bit,PDC bit,hole opener,single cone bit and drag bit.with advanced CNC machines and R&D team and on-time delivery. We have kept our clients ahead of schedule and under budget by providing the highest quality tools at the best possible prices .
    We ship to more than 40 different countries and serve industries such as Oil & Gas, water well , Construction,Mining,  Horizontal Directional Drilling (HDD), Geothermal and Environmental. Our experienced staff is here to assist you with everything from choosing the right bit to shipping around the globe.
     Our goal is to provide our customers with the best quality tools, accessories and service in the industry. We are supported by many years of experience, trained professionals and a full machine shop.  Reduce the cost ,Speed the drilling ,Guarantee the safety is always our aim.  We have been always insist on"Hengji bit,focusing on quality".

Main products
tricone bit(mill tooth and tungsten carbide insert tricone bit)
PDC bit(matrix body and steel body PDC bit)
hole opener(HDD rock reamer,barrel reamer,etc)
drag bit(step drag bit,PDC drag bit,chevron drag bit,etc)
accessories(single cone,bit breaker,nozzle ,etc)
