• Model NO.：32mm,34mm,36mm,38mm,42mm
• Bit Dia：32-42mm
• Weight：0.24-0.45kg
• Carbide Size：2*7 5*7 2*8, 5*9
• Sales Area：Many Country
• Color：According to The Customer Request
• Packaging：Standard Wooden Boxes or Pail
• Transport Package：Wooden Box or Carton Boxes
• Specification：ISO9001 SGS GE
• Trademark：Kato
• Origin：Liaocheng of Shandong Province
• HS Code：84314320
• Production Capacity：10000PCS,Pre Month

Basic Info.

Model NO. 32mm/34mm/36mm/38mm/42mm Bit Dia 32-42mm Weight 0.24-0.45kg Carbide Size 2*7 5*7 2*8, 5*9 Sales Area Many Country Color According to The Customer Request Packaging Standard Wooden Boxes or Pail Transport Package Wooden Box or Carton Boxes Specification ISO9001 SGS GE Trademark Kato Origin Liaocheng of Shandong Province HS Code 84314320 Production Capacity 10000PCS/Pre Month

Product Description

Product details:
1.Product Name:tungsten carbide Button Bit
TypesTapered chisel drill bits, Tapered cross drill bits, Tapered button drill bits
2.Application:Tapered drill bits are used in granite and marble quarry, gold mine, railway, tunnel, etc. for drilling
3.Feature:Tapered drill bits connect tapered drill steel of rock drill for drilling holes
4.Material:High quality carbide and high quality steel
5.MOQ:No requirement for testing and trial order
Rock Drill Tapered Button Bits is suitable for H22mm and H25mm taper rock drill rods use. It have three taper connection: 7°, 11°, 12°. It's widely used for hard rock(f=8~18) drilling use.
1) Tapered connection: 7,11,12
2) Alloy steel:42CrMo
3) Suitable carbide tips:YK20
4) Cross bit diameter: 30-42mm
5)Technology:hot-pressing or welding

According to the tungsten carbide insert, button bits can be divided into the types of hemispherical button, conical button and parabolic button, etc.
Button bits with hemispherical button is for high bearing capacity and abrasive resistance while conical button and parabolic button are for high drilling speed and low abrasive resistance.
When drilling, adjust the parameters of impulse and rotary with the standards of no jamming, high drilling speed and no bend of tapered drill rods.
Check the rock drill bits after each drilling. If the buttons are seriously worn, replace the button bits timely to ensure the drilling speed. If it's possible, grind the button bit for reusing. Replace the button bits once the taper worn, otherwise the buttons would be seriously abraded and even jammed.
We can design and manufature according to your requirment of diameter, number air holes and carbide button shape.

Product Name:	Tapper Button Bit
Description:	Tapered rock drilling tools is generally matched with the light-duty rock drill, It is widely used in metallurgy mine, geological exploration, water conservancy construction, electricity, traffic, tunnel, quarry stone project etc
Material:	carbide steel
MOQ:	50PCS
Tapered Type	T 7 ° ,T11 ° ,T12 °
Diameter	26mm-60mm
Weight	0.17kg-1.19kg
Use	Mining and drilling
Color	According to the customer request
