• Model NO.：metric and inch
• Size：6mm to 100mm
• Transport Package：Plastic Box
• Specification：metric and inch
• Trademark：stc
• Origin：Jiangsu
• HS Code：82075090
• Production Capacity：5000PCS,Size

Basic Info.

Model NO. metric and inch Size 6mm to 100mm Transport Package Plastic Box Specification metric and inch Trademark stc Origin Jiangsu HS Code 82075090 Production Capacity 5000PCS/Size

Product Description

DIN345 MORSE TAPER SHANK DRILL BITS

Din345 Morse taper shank drill bits are designed to fit ANS (MORSE) Taper Sockets and Sleeves. Features include a 118 Point and a Black-Oxide treatment that increases abrasion resistance, and helps eliminate chip welding. Morse taper shank drill bits can be used in a number of different types of applications and materials.

We use high quality high speed steel to make the bits.

Also we can follow DIN 346, GOST 10903, GOST 12121, GOST 2092.

Nominal diameter Dh8 mm	Overall length L mm	Shank diameter dh7 mm	Morse taper
12	199	101	2
13.2	199	101	2
13.5	206	108	2
14	206	108	2
18.25	256	135	3
18.5	256	135	3
18.75	256	135	3
19	256	135	3
19.25	261	140	3
19.50	261	140	3
19.75	261	140	3
20	261	140	3
20.25	266	145	3
20.5	266	145	3
20.75	266	145	3
21	266	145	3
21.25	271	150	3
21.50	271	150	3
21.75	271	150	3
22	271	150	3
22.25	271	150	3
22.5	276	155	3
22.75	276	155	3
23	276	155	3
26.75	319	170	4
27	319	170	4
27.25	319	170	4
27.5	319	170	4
27.75	319	170	4
28	319	170	4
28.25	324	175	4
28.5	324	175	4
28.75	324	175	4
29	324	175	4
29.25	324	175	4
29.5	324	175	4
29.75	324	175	4
30	324	175	4
30.25	329	180	4
30.5	329	180	4
30.75	329	180	4
31	329	180	4
31.25	329	180	4
31.5	329	180	4
31.75	334	185	4
40.50	392	205	5
41	392	205	5
41.5	392	205	5
42	392	205	5
42.5	392	205	5
43	397	210	5
43.5	397	210	5
44	397	210	5
44.5	397	210	5
45	397	210	5
45.5	402	215	5
46	402	215	5
46.5	402	215	5
47	402	215	5
47.5	402	215	5
48	407	220	5
48.5	407	220	5
49	407	220	5
49.5	407	220	5
50	407	220	5
