| SOLID CARBIDE JOBBERS LENGTH TWIST DRILLS | | | |
| • Precision ground to close diameter tolerances. | | | | | | | |
| • Recommended for general purpose drilling in Cast Iron, Aluminum,Magnesium, Bronze, Masonite and Resin-Fiberglass Laminates. | | | | | |
| Fractional Sizes | 118° Point, C2 Grade, Right Hand | | | | | | |
| | | | | | | | | | Flute | Overall | |
| | Flute | Overall | | | Flute | Overall | | Size | Length | Length | Model No. |
| Size | Length | Length | Model No. | Size | Length | Length | Model No. | 11/32 | 2-1/2 | 4" | 342-0022 |
| 1/32 | 3/8 | 1-1/8 | 342-0002 | 3/16 | 1-5/8 | 2-3/4 | 342-0012 | 23/64 | 2-3/4 | 4-1/4 | 342-0023 |
| 3/64 | 3/4 | 1-1/2 | 342-0003 | 13/64 | 1-3/4 | 3" | 342-0013 | 3/8 | 2-3/4 | 4-1/4 | 342-0024 |
| 1/16 | 3/4 | 1-1/2 | 342-0004 | 7/32 | 1-3/4 | 3" | 342-0014 | 25/64 | 2-7/8 | 4-1/2 | 342-0025 |
| 5/64 | 7/8 | 1-3/4 | 342-0005 | 15/64 | 2" | 3-1/4 | 342-0015 | 13/32 | 2-7/8 | 4-1/2 | 342-0026 |
| 3/32 | 1" | 2" | 342-0006 | 1/4 | 2" | 3-1/4 | 342-0016 | 27/64 | 2-7/8 | 4-1/2 | 342-0027 |
| 7/64 | 1-1/4 | 2-1/4 | 342-0007 | 17/64 | 2-1/8 | 3-1/2 | 342-0017 | 7/16 | 2-7/8 | 4-1/2 | 342-0028 |
| 1/8 | 1-1/4 | 2-1/4 | 342-0008 | 9/32 | 2-1/8 | 3-1/2 | 342-0018 | 29/64 | 3" | 4-3/4 | 342-0029 |
| 9/64 | 1-3/8 | 2-1/2 | 342-0009 | 19/64 | 2-3/8 | 3-3/4 | 342-0019 | 15/32 | 3" | 4-3/4 | 342-0030 |
| 5/32 | 1-3/8 | 2-1/2 | 342-0010 | 5/16 | 2-3/8 | 3-3/4 | 342-0020 | 31/64 | 3" | 4-3/4 | 342-0031 |
| 11/64 | 1-5/8 | 2-3/4 | 342-0011 | 21/64 | 2-1/2 | 4" | 342-0021 | 1/2 | 3" | 4-3/4 | 342-0032 |
