Supreme German Quality CT-4 Cross Cutter Hammer Drill Bit SDS Plus for Concrete Brick Stone Cement Reinforcement Drilling
ZHENJIANG HTT TOOL CO., LTD.- Customized：Customized
- Standard：DIN
- Length：110mm to 1000mm
- Type：Twist Drill Bit
- Material：Tungsten Carbide
- Usage：Masonry Drilling
Base Info
- Model NO.：2519
- Carbide Type：Ceratizit Bc20 CT-4
- Steel Type：40cr
- Flute Type：H-Plus
- Cutting Head：Splus Cross 4cutter
- Marking：Stamped
- Surface Treatment：Shot-Peened
- Shank Type：SDS Plus
- Welding Type：AVS. (Automatic Vacuum Soldering)
- Certificated：Bosch Audited SDS-Plus Logo
- Transport Package：Clip Hanger, Color Paper Hanger, Paper Box, Tubes
- Specification：5mm to 35mm diameter
- Trademark：OEM, HTT
- Origin：China
- HS Code：8207509000
- Production Capacity：2400000,Year
Description
| Item Number | Diameter(mm) | Working Length(mm) | Overall Length(mm) |
| 2519.05011 | 5 | 60 | 110 |
| 2519.05511 | 5.5 | 60 | 110 |
| 2519.06011 | 6 | 60 | 110 |
| 2519.06511 | 6.5 | 60 | 110 |
| 2519.07011 | 7 | 60 | 110 |
| 2519.08011 | 8 | 60 | 110 |
| 2519.10011 | 10 | 60 | 110 |
| 2519.05016 | 5 | 110 | 160 |
| 2519.05516 | 5.5 | 110 | 160 |
| 2519.06016 | 6 | 110 | 160 |
| 2519.06516 | 6.5 | 110 | 160 |
| 2519.07016 | 7 | 110 | 160 |
| 2519.08016 | 8 | 110 | 160 |
| 2519.10016 | 10 | 110 | 160 |
| 2519.12016 | 12 | 110 | 160 |
| 2519.14016 | 14 | 110 | 160 |
| 2519.16016 | 16 | 110 | 160 |
| 2519.18016 | 18 | 110 | 160 |
| 2519.20016 | 20 | 110 | 160 |
| 2519.22016 | 22 | 110 | 160 |
| 2519.24016 | 24 | 110 | 160 |
| 2519.25016 | 25 | 110 | 160 |
| 2519.26016 | 26 | 110 | 160 |
| 2519.28016 | 28 | 110 | 160 |
| 2519.30016 | 30 | 110 | 160 |
| 2519.32016 | 32 | 110 | 160 |
| 2519.35016 | 35 | 110 | 160 |
| 2519.05018 | 5 | 130 | 180 |
| 2519.05518 | 5.5 | 130 | 180 |
| 2519.06018 | 6 | 130 | 180 |
| 2519.06518 | 6.5 | 130 | 180 |
| 2519.08018 | 8 | 130 | 180 |
| 2519.10018 | 10 | 130 | 180 |
| 2519.05021 | 5 | 160 | 210 |
| 2519.05521 | 5.5 | 160 | 210 |
| 2519.06021 | 6 | 160 | 210 |
| 2519.06521 | 6.5 | 160 | 210 |
| 2519.07021 | 7 | 160 | 210 |
| 2519.08021 | 8 | 160 | 210 |
| 2519.10021 | 10 | 160 | 210 |
| 2519.12021 | 12 | 160 | 210 |
| 2519.14021 | 14 | 160 | 210 |
| 2519.16021 | 16 | 160 | 210 |
| 2519.18021 | 18 | 160 | 210 |
| 2519.20021 | 20 | 160 | 210 |
| 2519.22021 | 22 | 160 | 210 |
| 2519.24021 | 24 | 160 | 210 |
| 2519.25021 | 25 | 160 | 210 |
| 2519.26021 | 26 | 160 | 210 |
| 2519.28021 | 28 | 160 | 210 |
| 2519.30021 | 30 | 160 | 210 |
| 2519.32021 | 32 | 160 | 210 |
| 2519.35021 | 35 | 160 | 210 |
| 2519.05026 | 5 | 210 | 260 |
| 2519.05526 | 5.5 | 210 | 260 |
| 2519.06026 | 6 | 210 | 260 |
| 2519.06526 | 6.5 | 210 | 260 |
| 2519.07026 | 7 | 210 | 260 |
| 2519.08026 | 8 | 210 | 260 |
| 2519.10026 | 10 | 210 | 260 |
| 2519.12026 | 12 | 210 | 260 |
| 2519.14026 | 14 | 210 | 260 |
| 2519.16026 | 16 | 210 | 260 |
| 2519.18026 | 18 | 210 | 260 |
| 2519.20026 | 20 | 210 | 260 |
| 2519.22026 | 22 | 210 | 260 |
| 2519.24026 | 24 | 210 | 260 |
| 2519.25026 | 25 | 210 | 260 |
| 2519.26026 | 26 | 210 | 260 |
| 2519.28026 | 28 | 210 | 260 |
| 2519.30026 | 30 | 210 | 260 |
| 2519.32026 | 32 | 210 | 260 |
| 2519.35026 | 35 | 210 | 260 |
| 2519.05031 | 5 | 260 | 310 |
| 2519.05531 | 5.5 | 260 | 310 |
| 2519.06031 | 6 | 260 | 310 |
| 2519.06531 | 6.5 | 260 | 310 |
| 2519.07031 | 7 | 260 | 310 |
| 2519.08031 | 8 | 260 | 310 |
| 2519.10031 | 10 | 260 | 310 |
| 2519.12031 | 12 | 260 | 310 |
| 2519.14031 | 14 | 260 | 310 |
| 2519.16031 | 16 | 260 | 310 |
| 2519.18031 | 18 | 260 | 310 |
| 2519.20031 | 20 | 260 | 310 |
| 2519.22031 | 22 | 260 | 310 |
| 2519.24031 | 24 | 260 | 310 |
| 2519.25031 | 25 | 260 | 310 |
| 2519.26031 | 26 | 260 | 310 |
| 2519.28031 | 28 | 260 | 310 |
| 2519.30031 | 30 | 260 | 310 |
| 2519.32031 | 32 | 260 | 310 |
| 2519.35031 | 35 | 260 | 310 |
| 2519.05035 | 5 | 300 | 350 |
| 2519.05535 | 5.5 | 300 | 350 |
| 2519.06035 | 6 | 300 | 350 |
| 2519.06535 | 6.5 | 300 | 350 |
| 2519.07035 | 7 | 300 | 350 |
| 2519.08035 | 8 | 300 | 350 |
| 2519.10035 | 10 | 300 | 350 |
| 2519.12035 | 12 | 300 | 350 |
| 2519.14035 | 14 | 300 | 350 |
| 2519.16035 | 16 | 300 | 350 |
| 2519.18035 | 18 | 300 | 350 |
| 2519.20035 | 20 | 300 | 350 |
| 2519.22035 | 22 | 300 | 350 |
| 2519.24035 | 24 | 300 | 350 |
| 2519.25035 | 25 | 300 | 350 |
| 2519.26035 | 26 | 300 | 350 |
| 2519.28035 | 28 | 300 | 350 |
| 2519.30035 | 30 | 300 | 350 |
| 2519.32035 | 32 | 300 | 350 |
| 2519.35035 | 35 | 300 | 350 |
| 2519.05041 | 5 | 360 | 410 |
| 2519.05541 | 5.5 | 360 | 410 |
| 2519.06041 | 6 | 360 | 410 |
| 2519.06541 | 6.5 | 360 | 410 |
| 2519.07041 | 7 | 360 | 410 |
| 2519.08041 | 8 | 360 | 410 |
| 2519.10041 | 10 | 360 | 410 |
| 2519.12041 | 12 | 360 | 410 |
| 2519.14041 | 14 | 360 | 410 |
| 2519.16041 | 16 | 360 | 410 |
| 2519.18041 | 18 | 360 | 410 |
| 2519.20041 | 20 | 360 | 410 |
| 2519.22041 | 22 | 360 | 410 |
| 2519.24041 | 24 | 360 | 410 |
| 2519.25041 | 25 | 360 | 410 |
| 2519.26041 | 26 | 360 | 410 |
| 2519.28041 | 28 | 360 | 410 |
| 2519.30041 | 30 | 360 | 410 |
| 2519.32041 | 32 | 360 | 410 |
| 2519.35041 | 35 | 360 | 410 |
| 2519.05046 | 5 | 410 | 460 |
| 2519.05546 | 5.5 | 410 | 460 |
| 2519.06046 | 6 | 410 | 460 |
| 2519.06546 | 6.5 | 410 | 460 |
| 2519.07046 | 7 | 410 | 460 |
| 2519.08046 | 8 | 410 | 460 |
| 2519.10046 | 10 | 410 | 460 |
| 2519.12046 | 12 | 400 | 460 |
| 2519.14046 | 14 | 400 | 460 |
| 2519.16046 | 16 | 400 | 460 |
| 2519.18046 | 18 | 400 | 460 |
| 2519.20046 | 20 | 400 | 460 |
| 2519.22046 | 22 | 400 | 460 |
| 2519.24046 | 24 | 400 | 460 |
| 2519.25046 | 25 | 400 | 460 |
| 2519.26046 | 26 | 400 | 460 |
| 2519.28046 | 28 | 400 | 460 |
| 2519.30046 | 30 | 400 | 460 |
| 2519.32046 | 32 | 400 | 460 |
| 2519.35046 | 35 | 400 | 460 |
| 2519.06055 | 6 | 500 | 550 |
| 2519.06555 | 6.5 | 500 | 550 |
| 2519.07055 | 7 | 500 | 550 |
| 2519.08055 | 8 | 500 | 550 |
| 2519.10055 | 10 | 500 | 550 |
| 2519.12055 | 12 | 500 | 550 |
| 2519.14055 | 14 | 500 | 550 |
| 2519.16055 | 16 | 500 | 550 |
| 2519.18055 | 18 | 500 | 550 |
| 2519.20055 | 20 | 500 | 550 |
| 2519.22055 | 22 | 500 | 550 |
| 2519.24055 | 24 | 500 | 550 |
| 2519.25055 | 25 | 500 | 550 |
| 2519.26055 | 26 | 500 | 550 |
| 2519.28055 | 28 | 500 | 550 |
| 2519.30055 | 30 | 500 | 550 |
| 2519.32055 | 32 | 500 | 550 |
| 2519.35055 | 35 | 500 | 550 |
| 2519.0606 | 6 | 550 | 600 |
| 2519.0656 | 6.5 | 550 | 600 |
| 2519.0706 | 7 | 550 | 600 |
| 2519.0806 | 8 | 550 | 600 |
| 2519.1006 | 10 | 550 | 600 |
| 2519.1206 | 12 | 550 | 600 |
| 2519.1406 | 14 | 550 | 600 |
| 2519.1606 | 16 | 550 | 600 |
| 2519.1806 | 18 | 550 | 600 |
| 2519.2006 | 20 | 550 | 600 |
| 2519.2206 | 22 | 550 | 600 |
| 2519.2406 | 24 | 550 | 600 |
| 2519.2506 | 25 | 550 | 600 |
| 2519.2606 | 26 | 550 | 600 |
| 2519.2806 | 28 | 550 | 600 |
| 2519.3006 | 30 | 550 | 600 |
| 2519.3206 | 32 | 550 | 600 |
| 2519.3506 | 35 | 550 | 600 |
| 2519.0808 | 8 | 750 | 800 |
| 2519.1008 | 10 | 750 | 800 |
| 2519.1208 | 12 | 750 | 800 |
| 2519.1408 | 14 | 750 | 800 |
| 2519.1608 | 16 | 750 | 800 |
| 2519.1808 | 18 | 750 | 800 |
| 2519.2008 | 20 | 750 | 800 |
| 2519.2208 | 22 | 750 | 800 |
| 2519.2408 | 24 | 750 | 800 |
| 2519.2508 | 25 | 750 | 800 |
| 2519.2608 | 26 | 750 | 800 |
| 2519.2808 | 28 | 750 | 800 |
| 2519.3008 | 30 | 750 | 800 |
| 2519.3208 | 32 | 750 | 800 |
| 2519.3508 | 35 | 750 | 800 |
| 2519.101 | 10 | 950 | 1000 |
| 2519.121 | 12 | 950 | 1000 |
| 2519.141 | 14 | 950 | 1000 |
| 2519.161 | 16 | 950 | 1000 |
| 2519.181 | 18 | 950 | 1000 |
| 2519.201 | 20 | 950 | 1000 |
| 2519.221 | 22 | 950 | 1000 |
| 2519.241 | 24 | 950 | 1000 |
| 2519.251 | 25 | 950 | 1000 |
| 2519.261 | 26 | 950 | 1000 |
| 2519.281 | 28 | 950 | 1000 |
| 2519.301 | 30 | 950 | 1000 |
| 2519.321 | 32 | 950 | 1000 |
| 2519.351 | 35 | 950 | 1000 |
