• Model NO.：YXQ140
• Origin：China
• HS Code：8413910000
• Production Capacity：500sets,Month

Basic Info.

Model NO. YXQ140 Origin China HS Code 8413910000 Production Capacity 500sets/Month

Product Description

XQ140/12YA Hydraulic Power tong
12YA hydraulic power tong force in the oil field workover operations on dumping 2³/₈" ,-3½"drill pipe, and 2 ⁷/₈"- 4½" tubing and 4½"-5½" casing of a dynamic open-clamp . It has the following features:
1, the clamp from the torque hydraulic motor driven back by clamp rack plunger drive, drive concise, compact structure.
2, Lord, forceps are used in the dorsal surface of clamping rollers climbing, cards tight, reliable and timely release.
3, the first with the upper and lower clamp Fuzheng outside agencies, rotating stable, long service life.
4, Lord, matching clamp back, reversing valve can be manually manipulated simultaneous release clamping or string.
5, friction braking institutions in the clamp heads of the adjustment, maintenance more convenient.
6, and reset manually reversing valve knob with, for the flexible and convenient.
7, equipped with a retractable security doors installed, the protective effect from security

Technical parameters
1, the scope of application      Ø 73 -140mm          Low maximum torque           12kN.m  (8916 ft-lbs)
2, the lowest maximum torque       7.8 kN.m(5800 ft-lbs)       Maximum torque of the high-grade       4.2 kN.m(3123 ft-lbs)
3,the largest high-grade torque        2.6 kN.m  (1933 ft-lbs)    The largest high-grade speed          72r/min
4,the largest high-grade speed      42r/min
5,the largest of the low speed       24r/min       Low maximum speed          14r/min
6,the largest oil pressure         12MPa (1740 psi)        Of the largest oil supp            120r/min
7,Dimension (L * W * H) 1024*582*839mm
8,shipments quality              480kg
