• Model NO.：KCY-38DM
• Specification：CE certifacate
• Trademark：Cayken
• Origin：Shanghai
• Production Capacity：200

Basic Info.

Model NO. KCY-38DM Specification CE certifacate Trademark Cayken Origin Shanghai Production Capacity 200

Product Description

Product Feature:

1. With soft-starting, constant power.
2. With over-loading protection.
3. With stepless speed-regulating.
4. With high magnetic adhesion.
5. With coolant and lubricant integrated device.

Magnetic drill is a kind of lightweight magnetic core drill for adhering and drilling on the horizontal level, side face and top face, and widely used in the building, bridge building, and ship building industries and so on.

Parameter:

Product ModelKCY-28DMKCY-38DMKCY-55DM
Core Drill Range28MM38MM55MM
Rated Voltage110/220V110/220V110/220V
Rated Frequency50-60HZ50-60HZ50-60HZ
Rared Input Power1400W1650W1900W
No-Load Speed
650RPM
600RPM
550RPM
Max Attraction15800N17500N22000N
Max Stroke150mm180mm225mm
WEIGHT: 8KGS9KGS12KGS

Product Model	KCY-28DM	KCY-38DM	KCY-55DM
Core Drill Range	28MM	38MM	55MM
Rated Voltage	110/220V	110/220V	110/220V
Rated Frequency	50-60HZ	50-60HZ	50-60HZ
Rared Input Power	1400W	1650W	1900W
No-Load Speed	650RPM	600RPM	550RPM
Max Attraction	15800N	17500N	22000N
Max Stroke	150mm	180mm	225mm
WEIGHT:	8KGS	9KGS	12KGS
