Seamless Steel Tube High-Grade Steel Precision Wire-Line Core Drilling Rod
Forsun Ultra-hard Material Industry Co., Ltd.- Standard：RoHS, BS, DIN, JIS, AISI, API
- Length：0.5-3m
- Usage：Ore Mining
- Material：Carbon Steel
- Size：Aq Bq Nq Hq Pq
- Sizes：Aw Bw Nw Awj Bwj Awy Bwy Nwy
Base Info
- Model NO.：AQ BQ NQ HQ PQ
- Transport Package：Iron Reinforced Frame
- Specification：ISO9001
- Trademark：FORSUN
- Origin：Changsha Hunan
- HS Code：84314320
- Production Capacity：1000 PCS Per Month
Description
Size
OD (mm)
ID (mm)
AQ
44.7
37.3
BQ
55.7
46.1
NQ
70.0
60.2
HQ
89.0
78.0
PQ (PHD)
114.5
101.5
AW/ AWJ/AWY
43.7
30.7
BW/ BWJ/ BWY
54.0
38.0
NW/ NWY
66.8
51.0
HW
89.0
71.0
42mm
42.0
30.0
50mm
50.0
37.0
60mm
60.0
48.0
70mm
73.0
54.6
90mm
89.0
69.0
S75
71.0
61.0
Charators:
1, light weight (lighter than the old-fashioned drill pipe 45%)
2, footage soon, dust small vertical holes left after drilling cuttings, into a hole clear.
3, card beans quickly and easily connect and save banding material.
4, under separation of body and drilling may be the end, the use of life extended.
5, water-based wet good pass operation.
