Chtools Straight Shank Metal Drilling Spade Drill Bit

Zhejiang Xinxing Tools Co., Ltd.
  • Customized：Non-Customized
  • Length：Different Size
  • Type：Spade Drill
  • Material：Other
  • Usage：Metal Drilling
  • Groove Shape：Straight Flute

Base Info

  • Model NO.：SGS-
  • Shank Type：Lateral Fixation Type Straight Shank
  • Treatment：All-Ground
  • Performance：Better Endurance
  • Transport Package：Single Packing with PVC Plastic Tube
  • Specification：spade drill
  • Trademark：CHTOOLS
  • Origin：China(Mainland)Zhejiang
  • Production Capacity：100, 000PCS,Month

Description

20 series (Short Length)ConnectorTypeABCDEFGDrill Insert RangeMax.Drill DepthBody LengthRef.LengthOverall LengthShank DiaShank LengthPipe TapY0SGS-Y0-MK020-20N 9.5-11.031.861.163.5111.120.050.01/8"Z0SGS-Z0-MK020-20N11.5-12.531.861.163.5111.120.050.01/8"00SGS-00-MK020-20N13.0-15.034.963.566.3113.520.050.01/8"05SGS-05-MK020-20N15.5-17.534.963.566.3113.520.050.01/8"10SGS-10-MK025-20N18.0-21.566.7107.2110.7163.225.056.01/8"15SGS-15-MK025-20N22.0-24.066.7107.2110.7163.225.056.01/8"20SGS-20-MK032-20N25.0-29.085.7128.6132.2188.632.060.01/4"25SGS-25-MK032-20N30.0-35.085.7128.6132.2188.632.060.01/4"30SGS-30-MK040-20N36.0-41.0120.7173.0177.8243.040.070.01/4"35SGS-35-MK040-20N42.0-47.0120.7173.0177.8243.040.070.01/4"40SGS-40-MK040-20N48.0-55.0130.2179.4184.2249.440.070.01/4"45SGS-45-MK040-20N56.0-65.0130.2179.4184.2249.440.070.01/4"Chtools Straight Shank Metal Drilling Spade Drill Bit
