Diamond Core Drills for Reinforced Concrete
QUANZHOU HISEN DIAMOND TOOL CO., LTD.- Material：Diamond
- Customized：Customized
- Usage：Stone Cutting, Drilling, Engineering Material
- Specification：14mm to 500mm
- Cutting Materials：Reinforced Concrete
- Drilling Type：Wet Cutting
Base Info
- Model NO.：CBC
- Welded Type：Laser Welded
- Thread：Unc 1 1,4"-7
- Transport Package：Paper Carton & Color Boxes
- Trademark：OEM & ODM
- Origin：China
- Production Capacity：10000 PCS Per Month
Description
| Item No. |
Diameter mm |
Segment Height mm |
Segment width mm |
Valid Length mm |
| CBC16 | 16 | 10 | 2.5 | 400/450/500 |
| CBC18 | 18 | 10 | 2.5 | 400/450/500 |
| CBC20 | 20 | 10 | 2.5 | 400/450/500 |
| CBC22 | 22 | 10 | 2.5 | 400/450/500 |
| CBC24 | 24 | 10 | 2.5 | 400/450/500 |
| CBC26 | 26 | 10 | 2.5 | 400/450/500 |
| CBC28 | 28 | 10 | 3.0 | 400/450/500 |
| CBC32 | 32 | 10 | 3.0 | 400/450/500 |
| CBC35 | 35 | 10 | 3.0 | 400/450/500 |
| CBC38 | 38 | 10 | 3.0 | 400/450/500 |
| CBC40 | 40 | 10 | 3.0 | 400/450/500 |
| CBC44 | 44 | 10 | 3.0 | 400/450/500 |
| CBC52 | 52 | 10 | 3.5 | 400/450/500 |
| CBC62 | 62 | 10 | 3.5 | 400/450/500 |
| CBC77 | 77 | 10 | 3.5 | 400/450/500 |
| CBC83 | 83 | 10 | 3.5 | 400/450/500 |
| CBC102 | 102 | 10 | 3.5 | 400/450/500 |
| CBC108 | 108 | 10 | 3.5 | 400/450/500 |
| CBC112 | 112 | 10 | 3.5 | 400/450/500 |
| CBC122 | 122 | 10 | 3.5 | 400/450/500 |
| CBC127 | 127 | 10 | 3.5 | 400/450/500 |
| CBC132 | 132 | 10 | 3.5 | 400/450/500 |
| CBC152 | 152 | 10 | 4.0 | 400/450/500 |
| CBC162 | 162 | 10 | 4.0 | 400/450/500 |
| CBC177 | 177 | 10 | 4.0 | 400/450/500 |
| CBC182 | 182 | 10 | 4.0 | 400/450/500 |
| CBC200 | 200 | 10 | 4.0 | 400/450/500 |
| CBC225 | 225 | 10 | 4.5 | 400/450/500 |
| CBC253 | 253 | 10 | 4.5 | 400/450/500 |
| CBC300 | 250 | 10 | 5.0 | 400/450/500 |
| CBC350 | 350 | 10 | 5.0 | 400/450/500 |
| CBC400 | 400 | 10 | 5.0 | 400/450/500 |
| CBC500 | 500 | 10 | 5.5 | 400/450/500 |
