API 10d Standard Hinged Bow Spring Casing Centralizer
Puyang Zhongshi Group Co., Ltd.- Standard：API, ISO
- Usage：Well Drilling Machinery
- Material：Steel
- Type：Petroleum Drilling Tool & Accessory
- Tractor Hoist Type：Casing Centralizer
- Use：Horizontal Oil Well and Straight Wells
Base Info
- Model NO.：4.5" x 6"
- Lead Time：15 Days After Order
- Sample Time：5 Days
- Internal Diameter：4.5"
- Plate Thickness：3.8 Mm
- Surface Treatment：Electrostatic Painting
- Color：Red, Black, Orange or Others
- External Diameter：6"
- Transport Package：Standard Export Packaging, Wooden Case
- Specification：API 10D
- Trademark：PYZS
- Origin：China
- HS Code：73079900
- Production Capacity：50000 Set Per Month
Description
Casing & Hole Diameter
HEIGHT
MM
φ88.9mm*φ117.5mm(3½″×4 5/8″)
365
φ101.6mm*φ117.5mm(4″×4 5/8″)
365
φ114mm*φ152.4mm(4½″×6″)
365
φ127mm*φ152.4mm(5″×6″)
365
φ139.7mm*φ215.9mm(5½″×8½″)
365
φ139.7mm*φ241.3mm(5½″×9½″)
365
φ168.3mm*φ215.9mm(6 5/8″×8½″)
365
φ177.8mm*φ215.9mm(7″×8½″)
365
φ177.8mm*φ241.3mm(7″×9½″)
460
φ193.7mm*φ241.3mm(7 5/8″×9½″)
460
φ193.7mm*φ250.8mm(7 5/8″×9 7/8″)
460
φ244.5mm*φ311.2mm(9 5/8″×12 1/4″)
460
φ273mm*φ333mm(10 3/4″×13 1/8″)
460
φ339.7mm*φ444.5mm(13 3/8″×17½″)
560
φ406.4mm*φ508mm(16″×20″)
560
φ508mm*φ660.4mm(20″×26″)
560
