• Model NO.：05AGW
• Process：CBN Ground
• Thread：Machine Ground
• Shank：Weldon Shank
• Transport Package：Plastic Case
• Specification：See the table below
• Trademark：OEM available
• Origin：China
• HS Code：8207400000
• Production Capacity：500, 000 Pieces , Month

Basic Info.

Model NO. 05AGW Process CBN Ground Thread Machine Ground Shank Weldon Shank Transport Package Plastic Case Specification See the table below Trademark OEM available Origin China HS Code 8207400000 Production Capacity 500, 000 Pieces / Month

Product Description

Features:
Combination drill & tap, with 19mm (3/4") shank, provides hole drilling and top quality threads cutting in one work stroke every time. It delivers great time and efficiency saving when compared to conventional tapping applications.

Advantage:
1. Reduces set up time
2. NO NEED FOR TAP DRIVING EQUIPMENT
3. Correct core hole size and thread every time
4. Includes a safety recess at the end of the thread to avoid tool damage while threading
5. No more misalignment between core and tap
6. Simple to use, producing top quality threads
7. Suitable for plate with a thickness equal to the thread size

Industrial Applications:
1. General engineering
2. Truck and trailer manufacturing
3. Ship building and railroad
4. Elevator repair
5. Bridge and hiway maintenance
6. Construciton
7. Offshore rigs and piplines
8. Genral metal fabrications

Sizes available:

Size (mm)	Overal Length (mm)	Flute Length (mm)
M8 x 1.25	110	25
M10 x 1.5	113	28
M12 x 1.75	117	32
M14 x 2.0	117	36
M16 x 2.0	117	36
M18 x 1.5	130	40
M18 x 2.5	130	45
M20 x 2.5	135	45
M22 x 2.5	135	45
M24 x 3.0	148	54
M27 x 3.0	155	54
M30 x 3.5	169	63
