DTH Hammer Milling Bits Tungsten Carbide Button Drill Bit Inserts for Well
Shandong Yikuang Drilling Technology Co., Ltd.- Customized：Customized
- Standard：API
- Length：as Request
- Type：Center Drill Bit
- Material：Tungsten Carbide
- Usage：Well Drilling
Base Info
- Model NO.：DTH Hammer Drill Bit
- Product Name：DTH Hammer Bit
- Transport Package：Wooden Box
- Specification：6 inch
- Trademark：YIKUANG
- Origin：China
- HS Code：82071910
- Production Capacity：10000
Description
Hammer PRODUCT THREAD Mark 2"inch Hammer 3"inch Hammer 2 3/8 thread 4"inch Hammer 2 3/8 thread 5"inch Hammer 2 3/8 thread 6"inch Hammer 3 1/2 thread 7"inch Hammer 3 1/2 thread 8"inch Hammer 4 1/2 thread 10"inch Hammer 4 1/2 thread Ф85-90mm drill bit Side teeth,6/Φ14mm alloy. Side teeth,6/Φ16mm alloy. Ф91-105mm drill bit Side teeth,6/Φ14mm alloy. Φ110mm drill bit Side teeth,7/Φ14mm alloy. Customized products, no after-sales 3,Drill bit of 4 inch Hammer Ф105-109mm drill bit Side teeth,6/Φ14mm alloy. Ф110-115mm drill bit Side teeth,7/Φ14mm alloy. Side teeth,7/Φ16mm alloy. Ф116-120mm drill bit Side teeth,8/Φ14mm alloy. Ф121-130mm drill bit Side teeth,8/Φ14mm alloy. Side teeth,8/Φ16mm alloy. Ф131-140mm drill bit Side teeth,8/Φ16mm alloy. Customized products, no after-sales Ф141-150mm drill bit Side teeth,8/Φ18mm alloy. Customized products, no after-sales 4,Drill bit of 5 inch Hammer Ф132mm drill bit Side teeth,7/Φ16mm alloy. Ф133-140mm drill bit Side teeth,7/Φ18mm alloy. Side teeth,8/Φ16mm alloy. Side teeth,8/Φ18mm alloy. Ф144-146mm drill bit Side teeth,8/Φ18mm alloy. Ф147-152mm drill bit Side teeth,8/Φ18mm alloy. Ф153-165mm drill bit Side teeth,8/Φ18mm alloy. Customized products, no after-sales Ф166-178mm drill bit Side teeth,8/Φ18mm alloy. Customized products, no after-sales Ф179-190mm drill bit Side teeth,10/Φ18mm alloy. Customized products, no after-sales Ф191-203mm drill bit Side teeth,10/Φ18mm alloy. Customized products, no after-sales Ф204-216mm drill bit Side teeth,10/Φ18mm alloy. Customized products, no after-sales 5,Drill bit of 6 inch Hammer Ф152-165mm drill bit Side teeth,Φ18mm alloy. Ф166-180mm drill bit Side teeth,Φ18mm alloy. Ф181-190mm drill bit Side teeth,Φ18mm alloy. Ф191-203mm drill bit Side teeth,Φ18mm alloy. Customized products, no after-sales Ф204-219mm drill bit Side teeth,Φ18mm alloy. Customized products, no after-sales Ф220-235mm drill bit Side teeth,Φ18mm alloy. Customized products, no after-sales Ф236-254mm drill bit Side teeth,Φ18mm alloy. Customized products, no after-sales 6,Drill bit of 7 inch Hammer Ф180-190mm drill bit Side teeth,9/Φ18mm alloy. Ф191-195mm drill bit Side teeth,9/Φ18mm alloy. Ф196-203mm drill bit Side teeth,10/Φ18mm alloy. Ф204-219mm drill bit Side teeth,10/Φ18mm alloy. Customized products, no after-sales Ф220-235mm drill bit Side teeth,12/Φ18mm alloy. Customized products, no after-sales Ф236-254mm drill bit Side teeth,12/Φ18mm alloy. Customized products, no after-sales 7,Drill bit of 8 inch Hammer Ф195-203mm drill bit Side teeth,10/Φ18mm alloy. Side teeth,10/Φ19mm alloy. Ф204-219mm drill bit Side teeth,10/Φ18mm alloy. Side teeth,10/Φ19mm alloy. Ф220-235mm drill bit Side teeth,12/Φ18mm alloy. Ф236-245mm drill bit Side teeth,12/Φ18mm alloy. Ф246-254mm drill bit Side teeth,12/Φ18mm alloy. Customized products, no after-sales Ф255-275mm drill bit Side teeth,12/Φ18mm alloy. Customized products, no after-sales Ф276-305mm drill bit Side teeth,15/Φ18mm alloy. Customized products, no after-sales Ф306-325mm drill bit Side teeth,15/Φ18mm alloy. Customized products, no after-sales Ф326-350mm drill bit Side teeth,16/Φ18mm alloy. Customized products, no after-sales 8,Drill bit of 10 inch Hammer Ф240-254mm drill bit Side teeth,12/Φ18mm alloy . Ф255-275mm drill bit Side teeth,12/Φ18mm alloy. Ф276-290mm drill bit Side teeth,15/Φ18mm alloy. Ф291-305mm drill bit Side teeth,15/Φ18mm alloy. Ф306-320mm drill bit Side teeth,15/Φ18mm alloy. Ф321-335mm drill bit Side teeth,15/Φ18mm alloy. Customized products, no after-sales Ф366-350mm drill bit Side teeth,16/Φ18mm alloy. Customized products, no after-sales Ф351-375mm drill bit Side teeth,16/Φ18mm alloy. Customized products, no after-sales Ф376-400mm drill bit Side teeth,16/Φ18mm alloy. Customized products, no after-sales
The Yikuang Drilling ranges high quality rock drill bits is made of the most efficient high quality alloy steel.
Use quality forged steel, heat treatment and shot peening to provide a durable and reliable balance of strength and toughness.
1. Long life of bit: alloy steel material has a long service life, which is higher than similar products;
2. High drilling efficiency: the drill teeth are wear-resistant, so that the drill bit can always be sharp, thus greatly improving the entering speed of the teeth;
3.Steady drilling speed: the drill bit breaks the rock by scraping and cutting;
4. Good spacing effect: the new diamond head has strong abrasion resistance and good spacing performance, which enables the cutting teeth to be utilized efficiently;
5. Wide application range: it has been proved by practice that this drill bit is suitable for drilling in soft and medium hard formations, such as carbonate rock, limestone, cretaceous rock, clay rock, siltstone and sandstone (below grade 9 of drillability,).
Compared with general drills, especially in rock formations of grade 6-8, the effect is especially remarkable.
The submersible drill bit made by Yikuang Drilling ranges from 2 inches to 40 inches in diameter and has a variety of the most common end face shapes, alloy tooth styles and shank styles to match the application and rock formations you are drilling in.
We can customize the drill bit according to your requirement.
Different drill head shapes are selected according to different rock formations.
Bit face shape selection:
1. Drop Center Bit
For high penetration rates in soft to medium hard and fissured rock formations. Low to medium air pressures. Maximum hole deviation control.
2. Concave Face
The all-round application bit face specifically for medium hard and homogenerous rock formations. Good hole deviation control and good flushing capacity.
3. Convex Face
For high penetration rates in soft to medium-hard with low to medium air pressures. It is the most resistance to steel wash, and may reduce the load and wear on the gauge buttons, but poor hole deviation control.
4. Double Gauge Face
This kind of face shape is suitable for fast penetration rates in medium to hard rock formations. Designed for high air pressures and good resistance to steel wash step gauge bit.
5. Flat Face Bit
This kind of face shape is suitable for hard to very hard and abrasive rock formations in applications with high air pressures. Good penetration rates an resistance to steel wash.
The Yikuang Drilling ranges high quality rock drill bits is made of the most efficient high quality alloy steel.
Use quality forged steel, heat treatment and shot peening to provide a durable and reliable balance of strength and toughness.
1. Long life of bit: alloy steel material has a long service life, which is higher than similar products;
2. High drilling efficiency: the drill teeth are wear-resistant, so that the drill bit can always be sharp, thus greatly improving the entering speed of the teeth;
3.Steady drilling speed: the drill bit breaks the rock by scraping and cutting;
4. Good spacing effect: the new diamond head has strong abrasion resistance and good spacing performance, which enables the cutting teeth to be utilized efficiently;
5. Wide application range: it has been proved by practice that this drill bit is suitable for drilling in soft and medium hard formations, such as carbonate rock, limestone, cretaceous rock, clay rock, siltstone and sandstone (below grade 9 of drillability,).
Compared with general drills, especially in rock formations of grade 6-8, the effect is especially remarkable.
The submersible drill bit made by Yikuang Drilling ranges from 2 inches to 40 inches in diameter and has a variety of the most common end face shapes, alloy tooth styles and shank styles to match the application and rock formations you are drilling in.
We can customize the drill bit according to your requirement.
Different drill head shapes are selected according to different rock formations.
Bit face shape selection:
1. Drop Center Bit
For high penetration rates in soft to medium hard and fissured rock formations. Low to medium air pressures. Maximum hole deviation control.
2. Concave Face
The all-round application bit face specifically for medium hard and homogenerous rock formations. Good hole deviation control and good flushing capacity.
3. Convex Face
For high penetration rates in soft to medium-hard with low to medium air pressures. It is the most resistance to steel wash, and may reduce the load and wear on the gauge buttons, but poor hole deviation control.
4. Double Gauge Face
This kind of face shape is suitable for fast penetration rates in medium to hard rock formations. Designed for high air pressures and good resistance to steel wash step gauge bit.
5. Flat Face Bit
This kind of face shape is suitable for hard to very hard and abrasive rock formations in applications with high air pressures. Good penetration rates an resistance to steel wash.
FAQ:
Q: Are you a manufacturer or trading company?
A: We are a specialized manufacturer.
Q: What are your main products, and used for?
A: Our products hammer tools ,drill pipe and drill rig.They are used for mineral exploration, geological drilling,blast and quarry drilling .
Q: How about the delivery terms?
A: 1.Payment: T/T, L/C, Western Union, Paypal, 30% deposit in advance and rest before delivery
2. Min. order quantity: 1 piece.
3. Transportation: By sea, train or air flight.
Q: How about discount?
A: Price is based on products and order quantity.
Q: Do you accept sample order?
A: Yes sure, please contact us for details.
Q: How about your after-sales service?
A: As a manufacturer has 17 years of history we offer prompt technology support for all problems and questions. Besides, we accept goods return or replace for quality problem.
Q: Where is your factory located in?
A: Our factory is located in Linqing city, Shandong province, China.
Q: How does your company control the quality?
A: Quality first. In order to guarantee high quality for our products, our always make a serious inspection for all products and raw materials in strict procedure.
We have obtained certificate of ISO9001*Yikuang is professional production of drilling tools, if you want to know more about our products, please feel free to contact us.
