Concrete Wet Drilling Application Complete Diamond Core Drill

Quanzhou Keen Diamond Tool Co., Ltd.
  • Customized：Customized
  • Standard：SGS
  • Length：400-450mm
  • Type：Core Drill Bit
  • Material：Diamond
  • Usage：Well Drilling, Masonry Drilling, Concrete and Reinforced Concrete

Base Info

  • Model NO.：DCD
  • Thickness：5mm
  • Shape：Round
  • Manufacturing Arts：Brazed, Laser Welding, Jet, Impregnated
  • Kind：Diamond Drill
  • Brand：Keentool
  • Saw Blade External Diameter：16-500mm
  • Transport Package：Carton Box
  • Specification：Diameter 25-300mm
  • Trademark：KEENTOOL
  • Origin：Quanzhou, China
  • HS Code：8202
  • Production Capacity：2000PCS,Month

Description

Segment Dimensions
(mm)Segment nos.Length (mm)CouplingRemarksInchmm12516×3.3×103350-4501-1/4"-7 UNCLaser welding1 1/43216×3.3×104350-4501-1/4"-7 UNC1 1/23820x3.3x104350-4501-1/4"-7 UNC1 3/44420x3.5x105350-4501-1/4"-7 UNC25120x3.5x106350-4501-1/4"-7 UNC2 1/26420x3.5x108350-4501-1/4"-7 UNC37620x3.5x109350-4501-1/4"-7 UNC3 1/28920x3.5x1010350-4501-1/4"-7 UNC410220x3.8x1012350-4501-1/4"-7 UNC4 1/211420x4.2x1013350-4501-1/4"-7 UNC512720x4.2x1015350-4501-1/4"-7 UNC5 1/214024x4.2x1014350-4501-1/4"-7 UNC615224x4.5x1015350-4501-1/4"-7 UNC717824x4.5x1017350-4501-1/4"-7 UNC820324x4.5x1018350-4501-1/4"-7 UNC922924x5x1019350-4501-1/4"-7 UNC1025424x5x1020350-4501-1/4"-7 UNC1230524x5.5x1020350-4501-1/4"-7 UNCSilver welding1435624x5.5x10 350-450 Packaging & Shipping:
Packaging: Carton with water proof plastic.
Delivery time: In 15 days after receipt of paymentConcrete Wet Drilling Application Complete Diamond Core DrillConcrete Wet Drilling Application Complete Diamond Core DrillConcrete Wet Drilling Application Complete Diamond Core DrillConcrete Wet Drilling Application Complete Diamond Core DrillConcrete Wet Drilling Application Complete Diamond Core DrillConcrete Wet Drilling Application Complete Diamond Core DrillALWAYS AT YOUR SERVICE--KEENTOOL
