• Model NO.：DIN338
• Transport Package：Plastic Box
• Specification：QC
• Trademark：TOTAL
• Origin：Shanghai
• HS Code：8207509000
• Production Capacity：100000PCS,Month

Basic Info.

Model NO. DIN338 Transport Package Plastic Box Specification QC Trademark TOTAL Origin Shanghai HS Code 8207509000 Production Capacity 100000PCS/Month

Product Description

We are producing solid carbid cutting tools, drills, drill bit, Twist drill, twist drill set, HSS drills, cobalt drills, DIN338 straight shank twist drill, DIN1897 straight shank stub drill, DIN340 straight shank long twist drill, DIN345 taper shank drill, HSS step twist drill, taps and dies, taps, metric taps, screw tap, thread tap, machine taps, hand taps, straight fluted taps, spiral fluted taps, spiral point taps, nut taps, HSS screw tap, dies, machine dies, thread dies, round thread dies, adjustable round dies, hexagon dies, tap wrench, die handle, die holder, Center drill, double end drill, combined drill, countersinks, carbide center drill, Rotary files, end mills, Milling cutter, HSS step drill, step drill bit, Reamer, hole saw, bi-metal hole saw, hole cutter, tool bits, HSS tool bit, carbide tipped tool bit.

DIa	F. L	O. L	DIa	F. L	O. L	DIa	F. L	O. L
0.2	2.5	19	2.85	33	61	9.5	81	125
0.22	2.5	19	2.9	33	61	9.6	68	133
0.25	3	19	2.95	33	61	9.7	87	133
0.28	3	19	3	33	61	9.8	87	133
0.3	3	19	3.1	36	65	9.9	87	133
0.32	4	19	3.2	36	65	10	87	133
0.35	4	19	3.3	36	65	10.2	87	133
0.38	4	19	3.4	39	70	10.3	87	133
0.4	5	20	3.5	39	70	10.4	87	133
0.42	5	20	3.6	39	70	10.5	87	133
0.45	5	20	3.7	39	70	10.6	87	133
0.48	5	20	3.8	43	75	10.7	94	142
0.5	6	22	3.9	43	75	10.8	94	142
0.52	6	22	4	43	75	10.9	94	142
0.55	7	24	4.1	43	75	11	94	142
0.58	7	24	4.2	43	75	11.1	94	142
0.6	7	24	4.3	47	80	11.2	94	142
0.62	8	26	4.4	47	80	11.3	94	142
0.65	8	26	4.5	47	80	11.4	94	142
0.68	9	28	4.6	47	80	11.5	94	142
0.7	9	28	4.7	47	80	11.6	94	142
0.72	9	28	4.8	52	86	11.7	94	142
0.75	9	28	4.9	52	86	11.8	94	142
0.78	10	30	5	52	86	11.9	101	151
0.8	10	30	5.1	52	86	12	101	151
0.82	10	30	5.2	52	86	12.1	101	151
0.85	10	30	5.3	52	86	12.2	101	151
0.88	11	32	5.4	57	93	12.3	101	151
0.9	11	32	5.5	57	93	12.4	101	151
0.92	11	32	5.6	57	93	12.5	101	151
0.95	11	32	5.7	57	93	12.6	101	151
0.98	12	34	5.8	57	93	12.7	101	151
1	12	34	5.9	57	93	12.85	101	151
1.05	12	34	6	57	93	12.9	101	151
1.1	14	36	6.1	63	101	13	101	151
1.15	14	36	6.2	63	101	13.1	101	151
1.2	16	38	6.3	63	101	13.2	101	151
1.25	16	38	6.4	63	101	13.3	108	160
1.3	16	38	6.5	63	101	13.4	108	160
1.35	18	40	6.6	63	101	13.5	108	160
1.4	18	40	6.7	63	101	13.6	108	160
1.45	18	40	6.8	69	109	13.7	108	160
1.5	18	40	6.9	69	109	13.8	108	160
1.55	20	43	7	69	109	13.9	108	160
1.6	20	43	7.1	69	109	14	108	160
1.65	20	43	7.2	69	109	14.25	114	169
1.7	20	43	7.3	69	109	14.5	114	169
1.75	22	46	7.4	69	109	14.75	114	169
1.8	22	46	7.5	69	109	15	114	169
1.85	22	46	7.6	75	117	15.25	120	178
1.9	22	46	7.7	75	117	15.5	120	178
1.95	24	49	7.8	75	117	15.75	120	178
2	24	49	7.9	75	117	16	120	178
2.05	24	49	8	75	117	16.25	125	184
2.1	24	49	8.1	75	117	16.5	125	184
2.15	27	53	8.2	75	117	16.75	125	184
2.2	27	53	8.3	75	117	17	125	184
2.25	27	53	8.4	75	117	17.25	130	191
2.3	27	53	8.5	75	117	17.5	130	191
2.35	27	53	8.6	81	125	17.75	130	191
2.4	30	57	8.7	81	125	18	130	191
2.45	30	57	8.8	81	125	18.5	135	198
2.5	30	57	8.9	81	125	18.75	135	198
2.55	30	57	9	81	125	19	135	198
2.6	30	57	9.1	81	125	19.25	140	205
2.65	30	57	9.2	81	125	19.5	140	205
2.7	33	61	9.3	81	125	19.75	140	205
2.75	33	61	9.4	81	125	20	140	205
2.8	33	61



Dia	F. L	O. L	Dia	F. L	O. L	Dia	F. L	O. L
1	6	26	7.5	34	74	14	54	107
1.2	8	30	7.8	37	79	14.25	56	111
1.5	9	32	8	37	79	14.5	56	111
1.8	11	36	8.2	37	79	14.75	56	111
2	12	38	8.5	37	79	15	56	111
2.2	13	40	8.8	40	84	15.25	58	116
2.5	14	43	9	40	84	15.5	58	116
2.8	16	46	9.2	40	84	15.75	58	116
3	16	46	9.5	40	84	16	58	116
3.2	18	49	9.8	43	89	16.25	60	119
3.5	20	52	10	43	89	16.5	60	119
3.8	22	55	10.2	43	89	16.75	60	119
4	22	55	10.5	43	89	17	60	119
4.2	22	55	10.8	47	95	17.25	62	123
4.5	24	58	11	47	95	17.5	62	123
4.8	26	62	11.2	47	95	17.75	62	123
5	26	62	11.5	47	95	18	62	123
5.2	26	62	11.8	47	95	18.25	64	127
5.5	28	66	12	51	102	18.5	64	127
5.8	28	66	12.2	51	102	18.75	64	127
6	28	66	12.5	51	102	19	64	127
6.2	31	70	12.8	51	102	19.25	66	131
6.5	31	70	13	51	102	19.5	66	131
6.8	34	74	13.2	51	102	19.75	66	131
7	34	74	13.5	54	107	20	66	131
7.2	34	74	13.8	54	107
