Variable Helix Chip Breaker Shockwavehex Shank HSS Impact Drill Bit

Xuzhou Perfect Industry Technology Co., Limited
  • Customized：Customized
  • Standard：AISI, DIN338, Jobber Length
  • Length：Jobber-length
  • Type：Twist Drill Bit
  • Material：HSS and HSS Cobalt
  • Usage：Metal Drilling, Metal Stainless Steel Aluminium PVC Iron

Base Info

  • Model NO.：PFT066
  • Point Angle：135 Degree Point,Split Point with Chip Breaker
  • Surface：Tin-Coated
  • Size：1-20mm, 1,16"-1", #1-#90, a-Z
  • Processing：Fully Ground
  • Shank：Hex Shank
  • Transport Package：Metal Box
  • Specification：TUV, CE, ISO
  • Trademark：Perfect
  • Origin：Jiangsu Province, China
  • HS Code：8205100000
  • Production Capacity：5000PCS, Per Day

Description

Product NameHex Shank Variable Helix Chip Breaker HSS Drill Bit for MetalMaterial HSS  (HSS Cobalt is Available)Process Fully Ground   (Rolled & Polished, Rolled, Milled are Available)Standard

 DIN338               (Stub DIN1897, Long DIN340, Extra Long DIN1869,

                             Blacksmith Reduced Shank 10mm, 13mm, DIN345 Taper Shankare Available)

 Jobber Length  (Stub Screw Machine Length, Long Taper Length, Airctraft Extensoin,

                             Extra Long 12", 18", 24", Silver & Deming 1/2" Reduced Shank are Available)

Size 1 - 20mm, 1/16" - 1" , A - Z, 1# - 90#Point Type

 135 Split Point  With Chip Breaker

(118 Degree Regular Point, Turbo Max Point, Pilot Point are Available)

Shank Type

 Hex Shank  (Straight Shank, Tri-Flats Shank, Double R Hex Shank, Reduced Shank,

                      Threaded Hex Shank, Taper Shank are Available)

Helix Angle

 Variable Helix  Type W and Type H

(Slow Spiral Type H, Fast Spiral Type W, Left Hand Spiral are Available)

Web & Flute Type Heavy Duty Web with Regular Flute    (Heavy Duty Web with Parabolic Flute is Available)Surface Finish Titanium  (Bright, Black Oxide, Amber Color, Black & Gold, Black & Bright are Available)Package 10/5 Pcs in PVC Pouch, Plastic Box, Individually in Skin Card, Double Blister, Clamshell.Features

 1.Designed with a Variable Helix that with an aggressive 35° cutting edge which ends at 15°

 2.With Rapid Chip Removal to limit heat buildup to Stay Sharper Longer.

 3.The 135° split point tip delivers a precision start and prevents walking for fast, accurate holes.

 4.Come with a hex shank so you can toss it in your impact driver and go.

 5.Taper Connection Hex Shank specifically designed for better grip in a standard drill chuck.


Product sizes:

Variable Helix Chip Breaker Shockwavehex Shank HSS Impact Drill Bit
Other specification is also available according to your requirements. (OEM, ODM )
Pls. contact us freely for more information, I will reply you ASAP!
Hope you will enjoy a comfortable cooperation with us!


Shipping
1. FedEx/DHL/UPS/TNT for samples
 2. By Air or by Sea for batch goods, for FCL; Airport/ Port receiving;
 3. Customers specifying freight forwarders or negotiable shipping methods!
 4. Delivery Time: 3-7 days for samples; 5-25 days for batch goods.
