Hwl Std Type Diamond Bit Bq Aq Nq Hq Pq with Prime Material Impregnated Diamond Core Bits

Au-Prospect Drilling Tools(Wuxi)Co., Ltd.
  • Customized：Customized, Customized
  • Standard：Dcdma, Dcdma
  • Length：Stub-length, Stub-Length
  • Type：Core Drill Bit, Core Drill Bit
  • Material：Diamond, Diamond
  • Usage：Well Drilling, Coal,Overpass,Ore Ice Drilling, Well Drilling, Coal, Ore, Geological

Base Info

  • Model NO.：HWL
  • Certification：Dcdma
  • Transport Package：Wooden Box
  • Trademark：AU-PROSPECT
  • Origin：China
  • HS Code：730451
  • Production Capacity：100, 000PCS,Year

Description

 ImpregnatedBAU Imp(C=12) A12∅59.6 mm * ∅36.4  mmBAU Impregnated bit 12#Standard nozzle, drilling into hard formationNAU Imp(Turbo)15AC∅75.3mm * ∅47.6 mmNAU Turbo  15ACThe main nozzle design and the special soft matrix are suitable for drilling into hard formations and improving the drilling time efficiency.NAU3 Imp(FD)A10∅75.3mm * ∅45.1 mmNAU3 FD 10#Bottom water jet design, medium-hard matrix, suitable for drilling into medium-hard formations, with high core extraction rate.NAUTT Imp(C=12)A8∅75.3mm * ∅45.1 mmNAUTT Impregnated FD bit 8#Rectangular water fundus spray design, medium-hard matrix, suitable for drilling into medium-hard fractured formations.HAU Imp(C=12)A8∅95.6mm * ∅63.5 mmHAU Impregnated drill 8#Standard nozzle, drilling into medium-hard formationsHAU Imp(C=12)A10∅95.6mm * ∅63.5 mmHAU Impregnated bit10#Standard nozzle, drilling into medium-hard formationsHAU3 Imp(FD C=12)A10∅95.6mm * ∅61.1 mmHAU3 Impregnated FD bit  10#Bottom water jet design, drilling into medium-hard formationsHAU3 Imp(Deep groove C=12)A10∅95.6mm * ∅61.1 mmHAU3 Impregnated deep groove FD bit  10#Deep internal waterway design, drilling into broken medium-hard-hard formationsPAU Imp(C=9)A4∅122.1 mm * ∅85 mmPAU Impregnated bit 4#Drilling into broken soft groundPAU3 Imp(FD C=12)A8∅122.1 mm * ∅83 mmPAU3 Impregnated FD bit  8#Bottom water jet design, drilling into medium-hard formationsBTW Imp(C=12)15AC∅59.6 mm * ∅42  mmBTW Impregnated bit 15ACDrilling into hard formationsNTW Imp(C=12)A6∅75.3mm * ∅56 mmNTW Impregnated bit 6#Drilling into soft formationsNTW Imp(Turbo C=12)15R∅75.3mm * ∅56 mmNTW Turbo bit 15RThe main nozzle design and the special soft matrix are suitable for drilling into hard formations and improving the drilling time efficiency.

Recommended diamond size
The soft stratum uses the large grain diamond 15 grains/carat;
Medium grain diamond 20-30 grains/carat for medium and hard strata;
Hard formations use 40-60 grains of small diamond/carat.
2. Reaming Shell- Impregnated diamond bit types
Artificial diamond insert reamer: this product uses high grade artificial diamond and polycrystalline strip, the matrix wear resistance is high,the water performance is good, therefore the service life is long, the efficiency is high. Natural diamonds etreaming shell (Heavy duty): this product is made of high quality and selected natural diamond and polycrystalline, with high efficiency of water transfer performance, durability and satisfactory drilling efficiency . Mixed reaming shell (Super heavy duty): natural and artificial diamonds are mixed in the tire body during the production process to extend the service life and achieve the best time of reaming and drilling


3. Casing Shoes
Our company produces various specifications of diamond and carbide casing shoes, can be suitable for standard drilling or used for casing positioning in drilling. The casing has cut blocks on the front and outside of it. The inside is smooth, and the bore of the casing shoe is large enough for the drill bit and tool to pass through.
