• Model NO.：5D drills
• Movement Method：Contour Control
• Control Method：Closed-Loop Control
• Numerical Control：CNC,Mnc
• Processing Precision：±0.05mm
• Performance Classification：High-End CNC Machine Tools
• Condition：New
• Diameter：3-20mm
• Transport Package：1PCS in a Plastic Tube, 10PCS a Group
• Specification：SGS
• Trademark：Hiboo
• Origin：Changzhou Jiangsu China
• HS Code：8207709000
• Production Capacity：50000 PCS,Month

Basic Info.

Model NO. 5D drills Movement Method Contour Control Control Method Closed-Loop Control Numerical Control CNC/Mnc Processing Precision ±0.05mm Performance Classification High-End CNC Machine Tools Condition New Diameter 3-20mm Transport Package 1PCS in a Plastic Tube, 10PCS a Group Specification SGS Trademark Hiboo Origin Changzhou Jiangsu China HS Code 8207709000 Production Capacity 50000 PCS/Month

Product Description

High performance Carbide Drills for metal

Size : 3D,5D

Material : Imported AF, Sandvik,Kennametal carbide Rod.

Coating : AlTiN

	AlTiN	TiAIN	TiSiN	Nano
Hardness(HV)	3200	2800	3600	42(GPA)
Thickness(UM)	2.5-3	2.5-3	3	3
Oxidation Temp(°)	900	800	1000	1200
Friction Coeffient	0.3	0.3	0.45	0.4
Color	Black	Violet	Copper	Blue

Standard: DIN338 ,DIN 6527 etc.

Hardness: HRC55,HRC60



Shank dia (mm) Flute dia (mm) Flute Length (mm) O.A.L(mm) 3xD 6 M 3.4 20 62 3xD 6 M. 3.5 20 62 3xD 6 M. 3.8 24 66 3xD 6 M. 4 24 66 3xD 6 M. 4.2 24 66 3xD 6 M. 4.3 24 66 3xD 6 M. 4.5 24 66 3xD 6 M. 4.8 28 66 3xD 6 M. 5 28 66 3xD 6 M 5.1 28 66 3xD 6 M. 5.2 28 66 3xD 6 M. 5.5 28 66 3xD 6 M. 5.8 28 66 3xD 6 M. 6 28 66 3xD 8 M. 6.1 34 79 3xD 8 M 6.2 34 79 3xD 8 M. 6.5 34 79 3xD 8 M. 6.8 34 79 3xD 8 M. 6.9 34 79 3xD 8 M. 7 34 79 3xD 8 M. 7. 41 79 3xD 8 M 7.5 41 79 3xD 8 M 7.8 41 79 3xD 8 M. 8 41 79 3xD 10 M. 8.1 47 89 3xD 10 M. 8.2 47 89 3xD 10 M 8.5 47 89 3xD 10 M. 8.6 47 89 3xD 10 M 8.8 47 89 3xD 10 M. 9 47 89 3xD 10 M. 9.2 47 89 3xD 10 M. 9.5 47 89 3xD 10 M. 9.8 47 89 3xD 10 MM.10 47 89 3xD 12 MM.10.2 55 102 3xD 12 MM.10.3 55 102 3xD 12 MM.10.5 55 102 3xD 12 MM.10.6 55 102 3xD 12 MM.10.8 55 102 3xD 12 MM.11 55 102 3xD 12 MM.11.2 55 102 3xD 12 MM.11.5 55 102 3xD 12 MM.11.8 55 102 3xD 12 MM.12 55 102 3xD 14 MM.12.2 60 107 3xD 14 MM.12.5 60 107 3xD 14 MM.13 60 107 3xD 14 MM.13.5 60 107 3xD 14 MM.14 60 107 3xD 16 MM.14.2 65 115 3xD 16 MM.14.5 65 115 3xD 16 MM.15 65 115 3xD 16 MM.15.5 65 115 3xD 16 MM.16 65 115

Shank dia (mm) Flute dia (mm) Flute Length (mm) O.A.L(mm) 5xD 6 M. 3 28 66 5xD 6 M. 3.3 28 66 5xD 6 M. 3.4 28 66 5xD 6 M 3.5 28 66 5xD 6 M. 3.8 36 74 5xD 6 M. 4 36 74 5xD 6 M. 4.2 36 74 5xD 6 M. 4.3 36 74 5xD 6 M. 4.5 36 74 5xD 6 M. 4.8 44 82 5xD 6 MM. 5 44 82 5xD 6 M. 5.1 44 82 5xD 6 M 5.2 44 82 5xD 6 M. 5.5 44 82 5xD 6 M 5.8 44 82 5xD 6 MM. 6 44 82 5xD 8 M. 6.1 53 91 5xD 8 M 6.2 53 91 5xD 8 M. 6.5 53 91 5xD 8 M 6.8 53 91 5xD 8 M. 6.9 53 91 5xD 8 MM. 7 53 91 5xD 8 M. 7.2 53 91 5xD 8 M. 7.5 53 91 5xD 8 M. 7.8 53 91 5xD 8 MM. 8 53 91 5xD 10 M 8.1 61 103 5xD 10 M 8.2 61 103 5xD 10 M. 8.5 61 103 5xD 10 M 8.6 61 103 5xD 10 M. 8.8 61 103 5xD 10 MM. 9 61 103 5xD 10 M. 9.2 61 103 5xD 10 M. 9.5 61 103 5xD 10 M 9.8 61 103 5xD 10 MM.10 61 103 5xD 12 MM.10.2 71 118 5xD 12 MM.10.3 71 118 5xD 12 MM.10.5 71 118 5xD 12 MM.10.6 71 118 5xD 12 MM.10.8 71 118 5xD 12 MM.11 71 118 5xD 12 MM.11.2 71 118 5xD 12 MM.11.5 71 118 5xD 12 MM.11.8 71 118 5xD 12 MM.12 71 118 5xD 14 MM.12.2 77 124 5xD 14 MM.12.5 77 124 5xD 14 MM.13 77 124 5xD 14 MM.13.5 77 124 5xD 14 MM.14 77 124 5xD 16 MM.14.2 83 133 5xD 16 MM.14.5 83 133 5xD 16 MM.15 83 133 5xD 16 MM.15.5 83 133 5xD 16 MM.16 83 133
