• Model NO.：SED-WFD
• Tip：Tungsten Carbide
• Shank：Hex
• Surface Coating：Blue,Red,Gold,Black etc
• Min Qty：1000PCS
• Transport Package：PVC Bag, Blister Card, Box etc
• Specification：SGS
• Trademark：EASYDRILL
• Origin：China
• HS Code：820750900
• Production Capacity：80, 000PCS,Month

Basic Info.

Model NO. SED-WFD Tip Tungsten Carbide Shank Hex Surface Coating Blue,Red,Gold,Black etc Min Qty 1000PCS Transport Package PVC Bag, Blister Card, Box etc Specification SGS Trademark EASYDRILL Origin China HS Code 820750900 Production Capacity 80, 000PCS/Month

Product Description

carbide tip Wood Forstner Drill Bits

1. TCT Hinge boring wood forstner bits with hex shank
2. Tungsten carbide tip
3. Surface finish: Sand plated, Blue paint ect.
4. Size: 10mm~100mm
5. Long life and high performance.
6. suitable for drilling wood, PVC and plastic
7. Super abrasion, high precision,light cutting and no burrs around hole side
8.The edge part formed in one piece by the full automatic digital control Grinder.
9. Concentricity of drill is below 0.01mm
10. Excellent effect for hard boars such as melamine panels
11. Customer design offered

Diameter Size(mm)	Shank Size(mm)	Overall Length(mm)	Diameter Size(mm)	Shank Size(mm)	Overall Length(mm)
15	10	57	12	10	70
16	10	57	15	10	70
17	10	57	16	10	70
18	10	57	17	10	70
19	10	57	18	10	70
20	10	57	19	10	70
21	10	57	20	10	70
22	10	57	21	10	70
23	10	57	22	10	70
24	10	57	23	10	70
25	10	57	24	10	70
26	10	57	25	10	70
27	10	57	26	10	70
28	10	57	27	10	70
30	10	57	28	10	70
33	10	57	29	10	70
35	10	57	30	10	70
38	10	57	33	10	70
40	10	57	35	10	70
50	10	57	38	10	70
			40	10	70
			50	10	70
			53	10	70
			55	10	70
			60	10	70
