Tube & Sheet Drill Bit
SHI WEI INDUSTRIAL CO., LIMITED- Customized：Customized
- Standard：DIN
- Type：Twist Drill Bit
- Material：High Speed Steel
- Usage：Metal Drilling
- Tip：Splint Poiint
Base Info
- Model NO.：20AGR
- Shank：Round , 3-Flat
- Process：CBN Fully Ground
- Finish：Bright Finish , Titanium Coating
- Transport Package：Plastic Box
- Origin：China
- HS Code：8205100000
Description
Basic Info.
Model NO. 20AGR Shank Round / 3-Flat Process CBN Fully Ground Finish Bright Finish / Titanium Coating Transport Package Plastic Box Origin China HS Code 8205100000Product Description
Features:
Burr free and vibratrion free drilling
No centering required, the drills do not run off center
Roring existing holes
Designed to drill sheet metal, pipes and profiles of steel, plexiglas, plastic
A variety of hole diameters (up to 60mm) can be drilled using onle one tool
Finish options: Bright finish / Titanium coating
Sizes available:
| Size (mm) | Overall Length (mm) | Shank (mm) |
| 3-14 | 58 | 6 |
| 6-20 | 63 | 8 |
| 5-20 | 75 | 8 |
| 8-20 | 68 | 8 |
| 3-22.5 | 85 | 8 |
| 5-24.5 | 87 | 10 |
| 16-30.5 | 79 | 9 |
| 26-40 | 86 | 10 |
| 3-31 | 102 | 10 |
| 36-50 | 89 | 13 |
| 40-61 | 98 | 13 |
