Drilling Tools

Home > Product > Drill Bit

Diamond Tools, Saw Blade and Segment, Diamond Core Drill Bits, Diamond Fickert, Polishing Pad, Magnesite Polisher, Concrete Polisher

Quanzhou Keen Diamond Tool Co., Ltd.
  • Customized：Customized
  • Standard：SGS
  • Length：400-450mm
  • Type：Core Drill Bit
  • Material：Diamond and Metal Powder
  • Usage：Masonry Drilling

Base Info

  • Model NO.：DB-400
  • Manufacturing Arts：Welding
  • Kind：Diamond Drill
  • Saw Blade External Diameter：400mm
  • Brand：Keentool
  • Item：Diamond Core Drill Bit Manufacturer
  • Application：Concrete, Marble, Granite Drilling
  • Segment Width：2.5,3.0,3.5,4.0mm
  • Segment Height：8mm
  • Transport Package：Carton Box
  • Specification：SGS
  • Trademark：KEENTOOL
  • Origin：Quanzhou, China
  • HS Code：82075010
  • Production Capacity：3000PCS,Month

Description

Segment DimensionsSegment Nos.LengthThreadRemarksInchmm12516×3.3×103300-500mm1-1/4"-7 UNCBrazed/Laser welded1 1/43216×3.3×104300-500mm1-1/4"-7 UNC1 1/23820x3.3x104300-500mm1-1/4"-7 UNC1 3/44420x3.5x105300-500mm1-1/4"-7 UNC25120x3.5x106300-500mm1-1/4"-7 UNC2 1/26420x3.5x108300-500mm1-1/4"-7 UNC37620x3.5x109300-500mm1-1/4"-7 UNC3 1/28920x3.5x1010300-500mm1-1/4"-7 UNC410220x3.8x1012300-500mm1-1/4"-7 UNC4 1/211420x4.2x1013300-500mm1-1/4"-7 UNC512720x4.2x1015300-500mm1-1/4"-7 UNC5 1/214024x4.2x1014300-500mm1-1/4"-7 UNC615224x4.5x1015300-500mm1-1/4"-7 UNC717824x4.5x1017300-500mm1-1/4"-7 UNC820324x4.5x1018300-500mm1-1/4"-7 UNC922924x5x1019300-500mm1-1/4"-7 UNC1025424x5x1020300-500mm1-1/4"-7 UNC1230524x5.5x1020300-500mm1-1/4"-7 UNCRemarks: Other specification is available as per customer's requirement.

When order diamond core drill bit manufacturer, please kindly inform the followings:
1). Diameter of the core drill
2). Specification of segments for core drill bits
3). The length of the core drill
4). The size and types of screw of joint
5). For what drilling use(granite, marble, concrete etc)
6). Other special requirements ( if any)Diamond Tools, Saw Blade and Segment, Diamond Core Drill Bits, Diamond Fickert, Polishing Pad, Magnesite Polisher, Concrete PolisherDiamond Tools, Saw Blade and Segment, Diamond Core Drill Bits, Diamond Fickert, Polishing Pad, Magnesite Polisher, Concrete PolisherDiamond Tools, Saw Blade and Segment, Diamond Core Drill Bits, Diamond Fickert, Polishing Pad, Magnesite Polisher, Concrete PolisherDiamond Tools, Saw Blade and Segment, Diamond Core Drill Bits, Diamond Fickert, Polishing Pad, Magnesite Polisher, Concrete PolisherDiamond Tools, Saw Blade and Segment, Diamond Core Drill Bits, Diamond Fickert, Polishing Pad, Magnesite Polisher, Concrete PolisherDiamond Tools, Saw Blade and Segment, Diamond Core Drill Bits, Diamond Fickert, Polishing Pad, Magnesite Polisher, Concrete PolisherDiamond Tools, Saw Blade and Segment, Diamond Core Drill Bits, Diamond Fickert, Polishing Pad, Magnesite Polisher, Concrete Polisher ALWAYS AT YOUR SERVICE--KEENTOOL
