Quick Change Natural Stone/Granite Drill Bit DIN6.35e
ZHENJIANG HTT TOOL CO., LTD.- Customized：Customized
- Standard：DIN
- Length：60mm to 600mm
- Type：Twist Drill Bit
- Material：Tungsten Carbide
- Usage：Masonry Drilling
Base Info
- Model NO.：3111
- Carbide Tip Type：Ceratizit B05 W Type
- Steel Shaft Type：40cr
- Flute Type：W5
- Shank Type：DIN6.35e
- Welding Type：AVS. (Automatic Vacuum Soldering)
- Surface Treatment：Shot-Peened
- Certificate：Pgm
- Transport Package：Paper Hanger, PVC Bag, Skin Pack, Blister Pack
- Specification：3mm to 16mm diameter
- Trademark：OEM, HTT
- Origin：China
- HS Code：8207509000
- Production Capacity：4800000
Description
Basic Info.
Model NO. 3111 Carbide Tip Type Ceratizit B05 W Type Steel Shaft Type 40cr Flute Type W5 Shank Type DIN6.35e Welding Type AVS. (Automatic Vacuum Soldering) Surface Treatment Shot-Peened Certificate Pgm Transport Package Paper Hanger, PVC Bag, Skin Pack, Blister Pack Specification 3mm to 16mm diameter Trademark OEM, HTT Origin China HS Code 8207509000 Production Capacity 4800000Product Description
* W type of middle centring carbide tip for fast position and drilling various stone, brick , concrete, granite, etc.* 3DMax designed flutes to speed the dust rejection for higher drilling speed in various masonry building materials.
* DIN6.35E quick change hex shank to avoid the slide-grip and secure the drill under heavy drilling work. To fit those quick changes DIN6.35E standard drill chuck and quick connectors.
*Other special sizes are available on the customers' special requests.
| Item Number | Diameter(mm) | Working Length(mm) | Overall Length(mm) | Shank Standard |
| 3111.030060 | 3 | 25 | 60 | DIN6.35E |
| 3111.030070 | 3 | 30 | 70 | DIN6.35E |
| 3111.030085 | 3 | 40 | 85 | DIN6.35E |
| 3111.030090 | 3 | 50 | 90 | DIN6.35E |
| 3111.030095 | 3 | 50 | 95 | DIN6.35E |
| 3111.030100 | 3 | 50 | 100 | DIN6.35E |
| 3111.040075 | 4 | 30 | 75 | DIN6.35E |
| 3111.040085 | 4 | 40 | 85 | DIN6.35E |
| 3111.040090 | 4 | 50 | 90 | DIN6.35E |
| 3111.040100 | 4 | 60 | 100 | DIN6.35E |
| 3111.040105 | 4 | 60 | 105 | DIN6.35E |
| 3111.040150 | 4 | 110 | 150 | DIN6.35E |
| 3111.050085 | 5 | 40 | 85 | DIN6.35E |
| 3111.050090 | 5 | 45 | 90 | DIN6.35E |
| 3111.050095 | 5 | 50 | 95 | DIN6.35E |
| 3111.050100 | 5 | 60 | 100 | DIN6.35E |
| 3111.050105 | 5 | 60 | 105 | DIN6.35E |
| 3111.050150 | 5 | 110 | 150 | DIN6.35E |
| 3111.050250 | 5 | 200 | 250 | DIN6.35E |
| 3111.050300 | 5 | 250 | 300 | DIN6.35E |
| 3111.050400 | 5 | 260 | 400 | DIN6.35E |
| 3111.050500 | 5 | 360 | 500 | DIN6.35E |
| 3111.055085 | 5.5 | 40 | 85 | DIN6.35E |
| 3111.055090 | 5.5 | 50 | 90 | DIN6.35E |
| 3111.055095 | 5.5 | 50 | 95 | DIN6.35E |
| 3111.055100 | 5.5 | 60 | 100 | DIN6.35E |
| 3111.055150 | 5.5 | 110 | 150 | DIN6.35E |
| 3111.060085 | 6 | 40 | 85 | DIN6.35E |
| 3111.060090 | 6 | 50 | 90 | DIN6.35E |
| 3111.060100 | 6 | 60 | 100 | DIN6.35E |
| 3111.060115 | 6 | 65 | 115 | DIN6.35E |
| 3111.060150 | 6 | 110 | 150 | DIN6.35E |
| 3111060200 | 6 | 130 | 200 | DIN6.35E |
| 3111.060250 | 6 | 180 | 250 | DIN6.35E |
| 3111.060300 | 6 | 230 | 300 | DIN6.35E |
| 3111.060400 | 6 | 340 | 400 | DIN6.35E |
| 3111.060600 | 6 | 460 | 600 | DIN6.35E |
| 3111.065100 | 6.5 | 60 | 100 | DIN6.35E |
| 3111.065115 | 6.5 | 65 | 115 | DIN6.35E |
| 3111.06515 | 6.5 | 110 | 150 | DIN6.35E |
| 3111.065200 | 6.5 | 130 | 200 | DIN6.35E |
| 3111.065250 | 6.5 | 180 | 250 | DIN6.35E |
| 3111.065300 | 6.5 | 230 | 300 | DIN6.35E |
| 3111.065400 | 6.5 | 340 | 400 | DIN6.35E |
| 3111.070090 | 7 | 50 | 90 | DIN6.35E |
| 3111.070100 | 7 | 60 | 100 | DIN6.35E |
| 3111.070120 | 7 | 80 | 120 | DIN6.35E |
| 3111.070150 | 7 | 110 | 150 | DIN6.35E |
| 3111.070300 | 7 | 230 | 300 | DIN6.35E |
| 3111.070400 | 7 | 340 | 400 | DIN6.35E |
| 3111.070500 | 7 | 360 | 500 | DIN6.35E |
| 3111.080100 | 8 | 60 | 100 | DIN6.35E |
| 3111.080120 | 8 | 80 | 120 | DIN6.35E |
| 3111.080125 | 8 | 80 | 125 | DIN6.35E |
| 3111.080150 | 8 | 110 | 150 | DIN6.35E |
| 3111.080200 | 8 | 130 | 200 | DIN6.35E |
| 3111.080260 | 8 | 190 | 260 | DIN6.35E |
| 3111.080300 | 8 | 230 | 300 | DIN6.35E |
| 3111.080400 | 8 | 340 | 400 | DIN6.35E |
| 3111.080600 | 8 | 460 | 600 | DIN6.35E |
| 3111.090120 | 9 | 80 | 120 | DIN6.35E |
| 3111.090150 | 9 | 110 | 150 | DIN6.35E |
| 3111.100120 | 10 | 80 | 120 | DIN6.35E |
| 3111.100150 | 10 | 110 | 150 | DIN6.35E |
| 3111.100200 | 10 | 135 | 200 | DIN6.35E |
| 3111.100260 | 10 | 190 | 260 | DIN6.35E |
| 3111.100300 | 10 | 230 | 300 | DIN6.35E |
| 3111.100400 | 10 | 340 | 400 | DIN6.35E |
| 3111.100600 | 10 | 460 | 600 | DIN6.35E |
| 3111.120130 | 12 | 80 | 130 | DIN6.35E |
| 3111.120150 | 12 | 90 | 150 | DIN6.35E |
| 3111.120200 | 12 | 150 | 200 | DIN6.35E |
| 3111.120260 | 12 | 150 | 260 | DIN6.35E |
| 3111.120300 | 12 | 230 | 300 | DIN6.35E |
| 3111.120400 | 12 | 340 | 400 | DIN6.35E |
| 3111.120600 | 12 | 460 | 600 | DIN6.35E |
| 3111.130130 | 13 | 80 | 130 | DIN6.35E |
| 3111.130160 | 13 | 90 | 150 | DIN6.35E |
| 3111.140150 | 14 | 90 | 150 | DIN6.35E |
| 3111.140200 | 14 | 135 | 200 | DIN6.35E |
| 3111.140260 | 14 | 200 | 260 | DIN6.35E |
| 3111.140300 | 14 | 230 | 300 | DIN6.35E |
| 3111.140400 | 14 | 340 | 400 | DIN6.35E |
| 3111.140600 | 14 | 460 | 600 | DIN6.35E |
| 3111.160150 | 16 | 90 | 150 | DIN6.35E |
| 3111.16020 | 16 | 135 | 200 | DIN6.35E |
| 3111.160250 | 16 | 200 | 260 | DIN6.35E |
| 3111.160300 | 16 | 230 | 300 | DIN6.35E |
| 3111.160400 | 16 | 340 | 400 | DIN6.35E |
| 3111.160600 | 16 | 460 | 600 | DIN6.35E |
