• Model NO.：4mm-45mm
• Classification：Hammer Drill
• Drill Brand：LC&Yc
• Applications：Building and Industrial
• Impact Drill Structure：Ball-Type
• Impact Drill Head：Impact Drill
• Drill Shape：Round
• Condition：New
• Transport Package：PVC Bag, Plastic Tube, Hanger, Skin Card...
• Specification：SGS, 6mm
• Trademark：LC & YC
• Origin：Zhejiang Hangzhou
• HS Code：8207509000
• Production Capacity：100000PCS,Month

Basic Info.

Model NO. 4mm-45mm Classification Hammer Drill Drill Brand LC&Yc Applications Building and Industrial Impact Drill Structure Ball-Type Impact Drill Head Impact Drill Drill Shape Round Condition New Transport Package PVC Bag, Plastic Tube, Hanger, Skin Card... Specification SGS, 6mm Trademark LC & YC Origin Zhejiang Hangzhou HS Code 8207509000 Production Capacity 100000PCS/Month

Product Description

SDS PLUS Drill Bits

. Impact-resistant and bend-resistant drill bit, guarantees longer life.
. Wide and deeply supported plate prevents the tip from breaking out.
. High-temperature-brazed tungsten carbide blades for fast, accurate and safe drilling.
. Large volume spiral flute enables optimum drilling dust removal.
. Low vibration guarantees fatigue-free working.
. Suitable for drilling holes in granite, concrete, masonry, limestone, natural and artificial stone and so on.

With professional technology, experience, and competitive prices, our products are more and more popular in the word, especially in America, Europe, Middle East, India, Indonesia etc.

No matter the order quantity is big or small, we always do our best for our customers at any time. Hope to cooperate with you for long times with firm relationships.

Manufacturing Process: Milled.
Body material: 40Cr,  Tip carbide material: YG8.
Shank: SDS plus, SDS max, hex, spline
 Flute: Double, single
Tip feature: Flat, cross, W, three
Surface treatment: White finish, Sandblast finish.
Packing: Plastic bag, Plastic tube, Hanger, Skin card
Diameter: 4-45mm
Length: 110-1000mm
Use for: For drilling stone, brick, concrete, marble, granite etc.

The drill body of carbide alloy electric hammer drill employs high grade ally steel. The drill tip is welded with YG carbide alloy. It can be used with various types of electric hammer and it is a widely applicable and high efficient drilling tool for construction or installation trade.

SDS Plus drill bits can be used with Electric Hammer of BOSCH Co., of AFG Co., of HILTI Co.., of HITACHIKOKL Co., of Toshiba Co., The shank is round with Dualarc dual keyway


Diameter x Overall Length	Working Code Length	Diameter x Overall Length	Working Code Length
4.0 x 110mm	45mm	13.0 x 160mm	80mm
4.0 x 160mm	95mm	13.0 x 210mm	130mm
5.0 x 110mm	45mm	13.0 x 260mm	180mm
5.0 x 160mm	95mm	13.0 x 300mm	220mm
5.0 x 210mm	147mm	13.0 x 460mm	380mm
5.0 x 310mm	247mm	14.0 x 160mm	80mm
5.5 x 110mm	45mm	14.0 x 200mm	120mm
5.5 x 160mm	95mm	14.0 x 260mm	180mm
5.5 x 210mm	147mm	14.0 x 300mm	220mm
5.5 x 260mm	197mm	14.0 x 460mm	380mm
5.5 x 310mm	247mm	14.0 x 600mm	520mm
6.0 x 110mm	45mm	14.0 x 1000mm	920mm
6.0 x 160mm	97mm	15.0 x 160mm	80mm
6.0 x 210mm	147mm	15.0 x 200mm	120mm
6.0 x 260mm	197mm	15.0 x 260mm	180mm
6.0 x 460mm	397mm	15.0 x 460mm	380mm
6.5 x 110mm	45mm	16.0 x 160mm	80mm
6.5 x 160mm	97mm	16.0 x 200mm	120mm
6.5 x 210mm	147mm	16.0 x 250mm	180mm
6.5 x 260mm	197mm	16.0 x 300mm	230mm
7.0 x 110mm	45mm	16.0 x 460mm	380mm
7.0 x 160mm	97mm	16.0 x 600mm	520mm
7.0 x 210mm	147mm	16.0 x 800mm	720mm
8.0 x 110mm	45mm	16.0 x 1000mm	920mm
8.0 x 160mm	97mm	17.0 x 200mm	120mm
8.0 x 210mm	147mm	18.0 x 200mm	120mm
8.0 x 260mm	197mm	18.0 x 250mm	175mm
8.0 x 310mm	247mm	18.0 x 300mm	220mm
8.0 x 460mm	397mm	18.0 x 460mm	380mm
8.0 x 610mm	545mm	18.0 x 600mm	520mm
9.0 x 160mm	97mm	18.0 x 1000mm	920mm
9.0 x 210mm	147mm	19.0 x 200mm	120mm
10.0 x 110mm	45mm	19.0 x 460mm	380mm
10.0 x 160mm	97mm	20.0 x 200mm	120mm
10.0 x 210mm	147mm	20.0 x 300mm	220mm
10.0 x 260mm	197mm	20.0 x 460mm	380mm
10.0 x 310mm	247mm	20.0 x 600mm	520mm
10.0 x 360mm	297mm	20.0 x 1000mm	920mm
10.0 x 460mm	397mm	22.0 x 250mm	175mm
10.0 x 600mm	537mm	22.0 x 450mm	370mm
10.0 x 1000mm	937mm	22.0 x 600mm	520mm
11.0 x 160mm	95mm	22.0 x 1000mm	920mm
11.0 x 210mm	145mm	24.0 x 250mm	175mm
11.0 x 260mm	195mm	24.0 x 450mm	370mm
11.0 x 300mm	235mm	25.0 x 250mm	175mm
12.0 x 160mm	85mm	25.0 x 450mm	370mm
12.0 x 210mm	135mm	25.0 x 600mm	520mm
12.0 x 260mm	185mm	25.0 x 1000mm	920mm
12.0 x 310mm	235mm	26.0 x 250mm	175mm
12.0 x 460mm	385mm	26.0 x 450mm	370mm
12.0 x 600mm	525mm	28.0 x 450mm	370mm
12.0 x 1000mm	920mm	30.0 x 460mm	380mm

Customer questions & answers
Q: What's your MOQ?
A: Our MOQ is 100pcs for small sizes (dia.4mm-16mm, length 110mm-310mm), 50pcs or 20 pcs for big sizes (dia. 17mm-45mm, length 360mm - 1000mm).

Q: What's your payment terms?
A: We can do the below payment terms as below:
1. Order amount ≤ USD 3000, we do the payment term: T/T 100% in advance.
2. Order amount ≥USD 3000 and  ≤USD 20000, we do the payment term: T/T 20% in advance, the balance 70% will be paid against the copy of B/L after shipment.
3. Order amount ≥ USD 20000, we can do L/C at sight.
4. Some customer do business with us for long time and good reputation, we can do D/P at sight.

Q: What's the delivery time?
A:  30-45 days.

Q: Can I get free samples?
A: Yes, we could provide free samples and deliver with freight collected.

If you interest our products and want to know more informations about our products, please contact with me:

My name: Jocelyn
Mobile: 0086-13429197640
Office Phone: 0086-0571-89360992
Office Fax: 0086-0571-88303757
