Drill Bits with New Quadro Carbide Tip SDS Plus Rotary Hammer Drill Bits Used for Drilling Concrete

Hangzhou Lichang Tools Co., Ltd.
  • Type：Electric Hammer Drill Bit
  • Material：40cr Drill and Yg8c Tip
  • Usage：Concrete and Marble Drilling
  • Transport Package：PVC Bag, Plastic Tube, Hanger, Skin Card...
  • Specification：SGS
  • Trademark：customized

Base Info

  • Model NO.：4*110mm-45*1000mm
  • Origin：Zhejiang Hangzhou
  • HS Code：8207509000
  • Production Capacity：100000PCS,Month

Description

Basic Info.

Model NO. 4*110mm-45*1000mm Origin Zhejiang Hangzhou HS Code 8207509000 Production Capacity 100000PCS/Month

Product Description

Drill Bits with New Quadro Carbide Tip SDS Plus Rotary Hammer Drill Bits Used for Drilling ConcreteSDS PLUS HAMMER DRILL BIT, USE FOR CONCRETE

Material: 40 Chrome steel and YG8C carbide tip
Flute type: Single flute and double flute ( S4)
Professional Heat treatment
HRC: 47-55
Use for Concrete, stone.
Shank type: SDS PLUS shank and SDS MAX shank
Dia Size: 4-30mm  Length Size 110-1000mm
Packing: PVC bag, plastic tube,hanger and so on.

Employing high quality alloy steel for drilling body and tungsten carbide for drilling tip, and in combination with various types of electric hammer. The drill is one of the most efficient tools suitably and widely used for hole drilling in hard materials like concerte and brick in construction & installation industries. Available in sandblast, bright finish, black oxide, brown color etc.

Diameter x Overall LengthWorking Code LengthDiameter x Overall LengthWorking Code Length
4.0 x 110mm45mm13.0 x 160mm80mm
4.0 x 160mm95mm13.0 x 210mm130mm
5.0 x 110mm45mm13.0 x 260mm180mm
5.0 x 160mm95mm13.0 x 300mm220mm
5.0 x 210mm147mm13.0 x 460mm380mm
5.0 x 310mm247mm14.0 x 160mm80mm
5.5 x 110mm45mm14.0 x 200mm120mm
5.5 x 160mm95mm14.0 x 260mm180mm
5.5 x 210mm147mm14.0 x 300mm220mm
5.5 x 260mm197mm14.0 x 460mm380mm
5.5 x 310mm247mm14.0 x 600mm520mm
6.0 x 110mm45mm14.0 x 1000mm920mm
6.0 x 160mm97mm15.0 x 160mm80mm
6.0 x 210mm147mm15.0 x 200mm120mm
6.0 x 260mm197mm15.0 x 260mm180mm
6.0 x 460mm397mm15.0 x 460mm380mm
6.5 x 110mm45mm16.0 x 160mm80mm
6.5 x 160mm97mm16.0 x 200mm120mm
6.5 x 210mm147mm16.0 x 250mm180mm
6.5 x 260mm197mm16.0 x 300mm230mm
7.0 x 110mm45mm16.0 x 460mm380mm
7.0 x 160mm97mm16.0 x 600mm520mm
7.0 x 210mm147mm16.0 x 800mm720mm
8.0 x 110mm45mm16.0 x 1000mm920mm
8.0 x 160mm97mm17.0 x 200mm120mm
8.0 x 210mm147mm18.0 x 200mm120mm
8.0 x 260mm197mm18.0 x 250mm175mm
8.0 x 310mm247mm18.0 x 300mm220mm
8.0 x 460mm397mm18.0 x 460mm380mm
8.0 x 610mm545mm18.0 x 600mm520mm
9.0 x 160mm97mm18.0 x 1000mm920mm
9.0 x 210mm147mm19.0 x 200mm120mm
10.0 x 110mm45mm19.0 x 460mm380mm
10.0 x 160mm97mm20.0 x 200mm120mm
10.0 x 210mm147mm20.0 x 300mm220mm
10.0 x 260mm197mm20.0 x 460mm380mm
10.0 x 310mm247mm20.0 x 600mm520mm
10.0 x 360mm297mm20.0 x 1000mm920mm
10.0 x 460mm397mm22.0 x 250mm175mm
10.0 x 600mm537mm22.0 x 450mm370mm
10.0 x 1000mm937mm22.0 x 600mm520mm
11.0 x 160mm95mm22.0 x 1000mm920mm
11.0 x 210mm145mm24.0 x 250mm175mm
11.0 x 260mm195mm24.0 x 450mm370mm
11.0 x 300mm235mm25.0 x 250mm175mm
12.0 x 160mm85mm25.0 x 450mm370mm
12.0 x 210mm135mm25.0 x 600mm520mm
12.0 x 260mm185mm25.0 x 1000mm920mm
12.0 x 310mm235mm26.0 x 250mm175mm
12.0 x 460mm385mm26.0 x 450mm370mm
12.0 x 600mm525mm28.0 x 450mm370mm
12.0 x 1000mm920mm30.0 x 460mm380mm
